600x600 NEW Launched 595 x 595 x 20mm 36w Invisible LED Panel Light

Name: 600x600 NEW Launched 595 x 595 x 20mm 36w Invisible LED Panel Light
Brand: Cityghost
SKU: 129102563
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

LED Light Source:

3014

Warranty(Years):

Input Voltage(V):

100-265V

Shenzhen Cityghost Lighting Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source 3014

Warranty(Years) 3

Input Voltage(V) 100-265V

Lamp Power(W) 36

Lamp Luminous Flux(lm) 3096

Lamp Luminous Efficiency(lm/w) 86

Color Temperature(CCT) Other, COOL WIHTE, PURE WHITE, WARM WIHTE

Working Temperature(℃) -40, 50

Working Lifetime(Hour) 50000

Lamp Body Material PC

IP Rating IP44

Certification CCC, CE, EMC, LVD, SAA, UL

Place of Origin Guangdong, China

Brand Name Cityghost

Model Number Y66-36A

Specifications

1.595 x 595 24w invisible LED panel light
2.LED:SMD 3014
3.Three years warranty
4.CE RoHS approved
5.fireproof pc diffuse

Features

Patented product,with special design and high quality raw material,The lighting efficiency of some products can reach 100lm/W
Some types are assort in pairs with Mean well driver or Inventronics driver,drivers are UL/CE approved
With high quality 0.2W LED,high light efficiency and low light attenuation;Ordinary product L70lifespan > 50000h,high efficiency product L70 lifespan > 100000h
backlighting sources, with thickness of 19mm,and weight less than 10kg per square meter
different color temperature for your option,warm white 2800K-3200K,white 4500K-5000K,cold white 6000K-6500K
Easy installation without accessories
Beam angle:>110° RA>80 IP42 CLASSⅡ
High effciency conatant current driver can reach more than 90%,PF>0.9
Customized size can be accepted
Three years warranty.

Popular Models Specification

Model	QJL-Y66-36UL
Description	Build in invisible Constant current LED panel light
Dimension	595 x 595 x 20mm
Lighting source	SMD3014 LED 0.2W
LED QTY	180pcs
Power consumption	36W(includes driver)
Efficiency	≥88%
PF	≥0.90
Operation temperature	-30~+50°C
CCT	2700-3000K,4500-5000K,6000-6500K
Light efficiency(lm/W)	86Lm/W
Luminous	3096lm
Ra	Ra ≥ 80
Bean-angle	110 °
Protection grade	IP44
Temperature rising	< 20 °C
Relative humidity	10%-80%RH
Net Weight (includes driver)	3.2KG
Insulation class	CLASS II
Certificate	CE, RoHS,UL,PSE
Packing details	69CM X 64CM X 4.5CM,7.5KG
	68.5CM X 63.5CM X 20CM,22KG
	5psc
