Dry Fire Alarm Valve in Automatic Alarm Valve System

Name: Dry Fire Alarm Valve in Automatic Alarm Valve System
Brand: Minshan
SKU: 129098033
Availability: InStock

US$ 60 - 80 MOQ: 5 Sets

Key Specifications

Standard or Nonstandard:

Standard

Structure:

Other, Safety, Safety fire alarm valve

Pressure:

Other, Medium Pressure, High Pressure fire alarm valve

Fujian Minshan Fire-Fighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen China

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Standard

Structure Other, Safety, Safety fire alarm valve

Pressure Other, Medium Pressure, High Pressure fire alarm valve

Power Other, Hydraulic, Hydraulic fire alarm valve

Material Other, Casting, Brass, Cast Iron

Temperature of Media Medium Temperature

Media Water

Port Size DN100,DN150, DN200.

Place of Origin Fujian, China

Model Number ZSFC

Brand Name Minshan

Application General

Banner

dry fire alarm valve in automatic alarm valve system with ISO, CCC Certificates

1. Widely use in office, school, kitchen and warehouse;

2. Work by temperature sensitive;

3. Vairous types to choose;

4. Easy install and use.

5. OEM and ODM available

Characteristics and Functions
Model	ZSFC
Type	dry fire alarm valve in automatic alarm valve system
Material	Brass, Cast Iron
Norminal diameter	DN100,DN150, DN200.
Norminal working pressure	12bar
Strength test pressure	4.8Mpa
Flux(l/min)	15s
Structure	Safety fire alarm system
Power	Hydraulic fire alarm system
Pressure	High Pressure fire alarm system

Basic Parameters of Fire Alarm Valve
Model	Norminal Diameter(mm)	Norminal Working Pressure(MPa)	Body Height(mm)	Flange Outer Diameter (mm)	Water Pressure Reduced	Drive Time(s)
ZSFC100	DN100	1.2	250	220	<0.07	<15
ZSFC150	DN150	1.2	270	285	<0.07	<15
ZSFC200	DN200	1.2	370	340	<0.07	<15
