Ultra slim 9mm with remote control 40W 1195X295 (1200X300)
Specification & Parameter:
| Item Type: | led ceiling lighting panel |
| Item No.: | DC3-40 |
| Size(mm): | 1195*295*9mm |
| LED Type: | 0.2W SMD4014 |
| LED QTY: | 200 pcs |
| Input voltage(V) | AC 100-240V |
| Power consumption: | 40W, can be optional |
| Luminous: | 3400lm |
| Light Luminous Efficiency: | 85lm/w |
| Working Temperature: | -20c---+40c |
| Storage Temperature: | -40c---+85c |
| IP Rating: | IP44 |
| CRI : | Ra>80 |
| CCT: | 3000K/4000K/5000K/6000K |
| Beam angle | 120° |
| Light Body Material: | Aluminum Alloy |
| Working Lifetime: | 50000 Hours |
| Certification: | CE,RoHS |
| Warranty: | 3 years |
Culture Of Enterprise
1.Mission: Provide safe and reliable products to serve the community
2.Vision: Becoming a global manufacturer in lighting industry
3.Business Model: ODM, OEM
Our Service
1.Own an independent import & export rights which facilitate a convenient foreign trade.
2.OEM&ODM accepted
3.High efficient production ability, professional & humanized
“one-stop” after-sales service.
Our Team
1.Young, experienced and passionate team.
2. We insist holding the working philosophy “ Innovation. Commitment. Partnership! ”
Our Factory:
Q:Why are you choosing cityghost?
A:There are four reasons ,for confidence guarantee ,quality guarantee ,patent guarantee and certificated guarantee . Cityghost has specialized in led panel light for 5 years ,all the products employ fireproof materials ,and pass 850°C glow-wire flammability test .Technology innovations and utility patents to avoid patent disputes .TUV and BV certified manufacturer from Shenzhen , china.
Q: What is the type of your LED resources?
A: Our LED is 3014 for round panel,4014 for square panel and 5050 for RGB.Different color termperature for your option,3000k,40000k,5000k,6000k . The CRI is more than 80, and beam angle is biger than 110°.The lighting efficiency of our panel light average 3% more than other suppliers.
Q: What is the material of your LGP?
A: Our LGP is PMMA , and the thickness is 4mm ,which are from ChiMei Optoelectronics Corp or Mitsubi shi Corporation.
Q: What is the material of your Aluminum back and diffuser plate?
A: Our Aluminum back is 6063, and the thickness is 0.6mm.We use PC diffuser , and the thickness is 1.5mm.
Q: What are your available sizes?
A: We have many sizes such as
Diameter 134mm,163mm, 180mm,220mm,240mm,300mm;
square 195mm,295mm,595mm,620mm;
Rectangle: 595x295mm,1195x195mm,1195x295mm,1195x595mm;
All the sizes are our standard sizes.And if you needed , we supply customization service to some extent.
| Size | Power | LED Quantity | Input |
Light efficiency (lm/w) |
| 200x200mm |
12W | 60 | AC100-240V | 85 |
| 300x300mm | 24W | 120 | AC100-240V | 85 |
| 600x300mm | 30W | 150 | AC100-240V | 90 |
| 1200x200mm | 36W | 180 | AC100-240V | 95 |
| 1200x300mm | 30W | 150 | AC100-240V | 90 |
| 1200x600mm | 48W | 240 | AC100-240V | 95 |
| 620x620mm | 36W | 180 | AC100-240V | 95 |
| 603x603mm | 48W | 240 | AC100-240V | 95 |
Here comes other sides for options pls click if you like
600*600*19mm dimming led panel 1200*300*9ldimming panel 150*150*9mm dimming led panel
