PVC Yarn reinforced hose / pvc braided reinforced hose
DIMENSION | HOSE DIMEN SION | OPERATION PRESSURE | EXPLOSIVE PRESSURE | NET WEIGHT | MEASURE | ||
I.D | O.D | LENGTH | |||||
Inch | mm | mm | m | bar | bar | kg/roll | m3 |
5/32 | 4 | 9 | 100 | 12 | 50 | 6.3 | 0.01 |
1/4 | 6 | 10 | 100 | 8 | 45 | 6.2 | 0.03 |
1/4 | 6 | 11 | 100 | 1 | 65 | 8.3 | 0.03 |
5/16 | 8 | 12 | 100 | 7 | 40 | 8.4 | 0.032 |
5/16 | 8 | 13 | 100 | 10 | 58 | 10.0 | 0.032 |
3/8 | 9 | 14 | 100 | 10 | 48 | 11.2 | 0.035 |
3/8 | 10 | 14 | 100 | 7 | 35 | 9.6 | 0.035 |
3/8 | 10 | 15 | 100 | 9 | 45 | 12.2 | 0.035 |
1/2 | 12 | 16 | 100 | 7 | 38 | 11.2 | 0.045 |
1/2 | 12 | 17 | 100 | 8 | 43 | 14.2 | 0.045 |
1/2 | 13 | 17 | 100 | 5 | 30 | 12.5 | 0.045 |
1/2 | 13 | 18 | 100 | 8 | 401 | 15.0 | 0.045 |
5/8 | 16 | 20 | 50 | 5 | 28 | 7.0 | 0.04 |
5/8 | 16 | 21 | 50 | 8 | 35 | 9.0 | 0.04 |
3/4 | 19 | 24 | 50 | 4 | 25 | 10.5 | 0.044 |
3/4 | 19 | 25 | 50 | 8 | 32 | 12.5 | 0.069 |
1 | 25 | 30 | 50 | 4 | 23 | 12.0 | 0.069 |
1 | 25 | 31 | 50 | 6 | 28 | 15.0 | 0. |
