2015 New Item XYQ114/6YB Api Hydraulic Power Tong With Torque System

FOB Price

US$ 2,900 - 3,000 / Piece

1 Piece(Min. Order)

Port Shanghai TianJin Qingdao port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China		Brand Name	BLT
Model Number	XQ114/6YB		Type	Other, hydraulic drilling tools

Product Description

2015 New item XYQ114/6YB api hydraulic power tong with torque system

Specification

1. Tubing hydraulic power tong XQ114/6YB

2.well-servicing process

3.For tubing

4.API Standard

5.Size: 2-7/8,3 -1/2, 4-1/2" tubing

Detailed description

XQ114/6YB hydraulic power clamp is used for quick make-up/break-out in well service operations. It is mainly made up of two parts, master tong and backup tong. The pipe size range of master tong is Φ73-114 2⁷/8”-4¹/2”; the pipe size range of backup tong is Φ89-141.5 3¹/2”-5¹/8.

Model	XQ114/6YB
Pipe size range of master tong	Φ73-114 2⁷/8”-4¹/2”
Pipe size range of backup tong	Φ89-141.5 3¹/2”-5¹/8
High gear rated torque	1500 N.m 1106ft-lbs
Low gear rated torque	6000 N.m 4425 ft-lbs
Hige gear rated speed	85 r/min
Low gear rated speed	20 r/min
Rated operation pressure	11Mpa 1595psi
Max. Flow	100L/min 26gpm
Dimension:L×W×H	750×500×600 29.5” ×19.7” ×23.6”
Weight(including backup tong)	220kg 485 lbs
features
1.clamp the tubing use corresponding dies, jaw set or die seat.
2.torque control valve may be equiped according to customer’s request.
3.choose and buy lengthening guide pole assembly, the backup tong can clamp the tubing body
4.torque control system may be equiped according to customer’s request.

Detailed Pictures
