2015 hot sale XQ89/3YJ Tubing power tong for oil pipe

Model

XQ89/3YJ, 3YC, 3YB

Pipe size range of master tong

Φ60-89

2³/8”-3¹/2”

Pipe size range of backup tong

Φ60-114

2³/8”-4¹/2

High gear rated torque

1100 N.m

811ft-lbs

Low gear rated torque

3000 N.m

2213 ft-lbs

Hige gear rated speed

90 r/min

Low gear rated speed

30 r/min

Rated operation pressure

10Mpa

1450psi

Max. Flow

80L/min

21gpm

Dimension:L×W×H

650×430×550

25.6” ×16.9” ×21.7”

Weight(including backup tong)

158kg

348 lbs

features

1.clamp the tubing use corresponding dies, jaw set or die seat.

2.torque control valve may be equiped according to customer’s request.

3.choose and buy lengthening guide pole assembly, the backup tong can clamp the tubing body

4.torque control system may be equiped according to customer’s request.
