High quality API 5CT 8 5/8 N80 STC casing collars with API standard
- 80000 Piece / Pieces per Month
- Shanghai TianJin Qingdao
- T/T Credit Card
- coupling CZ50-250 for power station
- screw pump coupling HSNH280-54A for power plant
- Customized flexible steel motor shaft coupling pump coupling
- China manufacturer Motor side coupling DTPD30FM002 for power generation
- Made in China Type 03 Coupling U238/2ZT(DY) for thermal power plant
- Made in China Type 03 Coupling U238/2ZT(DY) for thermal power plant
Product Details
Structure: | Other, coupling | Flexible or Rigid: | Flexible | Standard or Nonstandard: | Standard |
Material: | Other, J55 K55 N80 L80 P110 | Brand Name: | BLT | Place of Origin: | Henan, China |
Model Number: | 8 5/8" N80 LTC |
Product Description
High quality API 5CT 8 5/8 N80 STC casing collars with API standard
Feature
1.Std Ref.: API 5CT 5B ISO9001, 2008
2.Grade: J55,K55, N80-1,N80-Q,L80,C90,P110
3.Size: tubing 1.9"to4-1/2", casing 4-1/2"to13-3/8"
Technical Parameter
Product Name | Specification | Type of thread | OD*L(mm) | Unit Weight |
High quality API 5CT 8 5/8 N80 STC casing collars with API standard
| 4-1/2" | STC | 127.00*158.75 | 5.23 |
4-1/2" | LTC | 127.00*177.80 | 4.15 | |
4-1/2" | BTC | 127.00*225.42 | 4.55 | |
5" | STC | 141.30*165.10 | 4.66 | |
5" | LTC | 141.30*196.85 | 5.75 | |
5" | BTC | 141.30*231.78 | 5.85 | |
5-1/2" | STC | 153.67*171.45 | 5.23 | |
5-1/2" | LTC | 153.67*203.20 | 6.42 | |
5-1/2" | BTC | 153.67*234.95 | 6.36 | |
6-5/8" | STC | 187.71*184.15 | 9.12 | |
6-5/8" | LTC | 187.71*222.25 | 11.34 | |
6-5/8" | BTC | 187.71*244.48 | 11.01 | |
7" | STC | 194.46*184.15 | 8.39 | |
7" | LTC | 194.46*228.60 | 10.83 | |
7" | BTC | 194.46*254.00 | 10.54 | |
7-5/8" | STC | 215.90*190.50 | 12.30 | |
7-5/8" | LTC | 215.90*234.95 | 15.63 | |
7-5/8" | BTC | 215.90*263.52 | 15.82 | |
8-5/8" | STC | 244.48*196.85 | 16.23 | |
8-5/8" | LTC | 244.48*254.00 | 21.67 | |
8-5/8" | BTC | 244.48*269.88 | 20.86 | |
9-5/8" | STC | 269.88*196.85 | 18.03 | |
9-5/8" | LTC | 269.88*266.70 | 25.45 | |
9-5/8" | BTC | 269.88*269.88 | 23.16 | |
10-3/4" | STC | 298.45*203.20 | 20.78 | |
10-3/4" | BTC | 298.45*269.88 | 25.74 | |
11-3/4' | STC | 323.85*203.20 | 22.64 | |
11-3/4' | BTC | 323.85*269.88 | 28.03 | |
13-3/8" | STC | 365.12*203.20 | 25.66 | |
13-3/8" | BTC | 365.12*269.88 | 31.77 | |
16" | STC | 431.80*228.6 | 34.91 | |
16" | BTC | 431.80*269.88 | 40.28 | |
18-5/8" | STC | 508.00*228.60 | 51.01 | |
18-5/8" | BTC | 508.00*269.88 | 62.68 | |
20" | STC | 533.40*228.6 | 43.42 | |
20" | LTC | 533.4*292.10 | 57.04 | |
20" | BTC | 533.40*269.88 | 50.10 |
Package information
Mq API Casing Couplings Short Thread | Casing Size OD (inches) | Coupling Size OD (inches) | Length (inches) | Weight per Coupling (kg) | Palletized Carton Quantity | Palletized Carton Weight(kg) |
STC (API 5CT Ninth Edition) | 4 1/2 | 5 | 6.25 | 3.62 | 392 | 1420 |
5 | 5.563 | 6.5 | 4.66 | 392 | 1827 | |
5 1/2 | 6.05 | 6.75 | 5.23 | 288 | 1507 | |
6 5/8 | 7.39 | 7.25 | 9.12 | 200 | 1824 | |
7 | 7.875 | 7.25 | 8.39 | 200 | 1678 | |
7 5/8 | 8.5 | 7.5 | 12.3 | 128 | 1575 | |
8 5/8 | 9.625 | 7.75 | 16.23 | 128 | 2078 | |
9 5/8 | 10.625 | 7.75 | 18.03 | 72 | 1299 | |
10 3/4 | 11.75 | 8 | 20.78 | 63 | 1310 | |
11 3/4 | 12.75 | 8 | 22.64 | 63 | 1427 | |
13 3/8 | 14.375 | 8 | 25.66 | 63 | 1617 | |
16 | 17 | 9 | 34.91 | 24 | 838 | |
18 5/8 | 20 | 9 | 54.01 | 24 | 1297 | |
20 | 21 | 9 | 43.42 | 24 | 1043 |
API Casing Couplings Long Thread | Casing Size OD (inches) | Coupling Size OD (inches) | Length (inches) | Weight per Coupling (kg) | Palletized Carton Quantity | Palletized Carton Weight(kg) |
LTC (API 5CT Ninth Edition) | 4 1/2 | 5 | 7 | 4.15 | 392 | 1627 |
5 | 5.563 | 7.75 | 5.75 | 343 | 1973 | |
5 1/2 | 6.05 | 8 | 6.42 | 252 | 1618 | |
6 5/8 | 7.39 | 8.75 | 11.34 | 150 | 1701 | |
7 | 7.875 | 9 | 10.83 | 150 | 1625 | |
7 5/8 | 8.5 | 9.25 | 15.63 | 96 | 1501 | |
8 5/8 | 9.625 | 10 | 21.67 | 96 | 2081 | |
9 5/8 | 10.625 | 10.5 | 25.45 | 45 | 1146 | |
20 | 21 | 11.5 | 57.04 | 20 | 1141 |
Certifications
Detailed pictures
Production Process
Workshop photos
