15w Surface Mounted Round Downlight Led 22v

15w Surface Mounted Round Downlight Led 22v thumbnail-1
15w Surface Mounted Round Downlight Led 22v thumbnail-2
15w Surface Mounted Round Downlight Led 22v thumbnail-3
15w Surface Mounted Round Downlight Led 22v thumbnail-4
15w Surface Mounted Round Downlight Led 22v thumbnail-5
15w Surface Mounted Round Downlight Led 22v thumbnail-6
15w Surface Mounted Round Downlight Led 22v photo-1
15w Surface Mounted Round Downlight Led 22v photo-2
15w Surface Mounted Round Downlight Led 22v photo-3
15w Surface Mounted Round Downlight Led 22v photo-4
15w Surface Mounted Round Downlight Led 22v photo-5
15w Surface Mounted Round Downlight Led 22v photo-6
US$ 3.9 - 18.54 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD5730
Warranty(Years):
2
Input Voltage(V):
AC85-265V
Contact Supplier Request Quote Chat Now
Jiangmen Allred Lighting Technology Co., LTD.
Payment & Shipping
Payment Methods:
Port of Shipment:
Jiangmen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD5730
Warranty(Years) 2
Input Voltage(V) AC85-265V
Lamp Power(W) 15
Lamp Luminous Flux(lm) 1200
Lamp Luminous Efficiency(lm/w) 80
Color Temperature(CCT) Warm White
Working Temperature(℃) -20, 40
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP33
Certification BV, CCC, CE, EMC
Model Number ARD-TD-B-5"-15W
Place of Origin Guangdong, China
Brand Name ALLRED

Product features

Our products are delicate, use high quality aluminum material, heat superior performance, strong applicability.

Products use imported illuminant, ensuring high brightness. The outer constant current drive power, stable performance.

15w surface mounted round downlight led 22v

Parameters

White frame black body 220v round downlight 15w 110v
Item number Voltage Power Chip LED qty Color temperature Size hole size
ARD-TD-B-2.5"-3W AC85~265V 3w SMD5730 9pcs 3000k/4000k/6000k φ90xH42mm φ75mm
ARD-TD-B-3"-5W AC85~265V 5w SMD5730 15pcs 3000k/4000k/6000k φ110xH48mm φ95mm
ARD-TD-B-3.5"-7W AC85~265V 7w SMD5730 21pcs 3000k/4000k/6000k φ115×H50mm φ100mm
ARD-TD-B-4"-12W AC85~265V 12w SMD5730 36pcs 3000k/4000k/6000k φ130×H66mm φ115mm
ARD-TD-B-5"-15W AC85~265V 15w SMD5730 45pcs 3000k/4000k/6000k φ160×H65mm φ140mm
ARD-TD-B-6"-18W AC85~265V 18w SMD5730 54pcs 3000k/4000k/6000k φ190×H80mm φ175mm
ARD-TD-B-8"-24W AC85~265V 24w SMD5730 72pcs 3000k/4000k/6000k φ240×H90mm φ210mm



15w surface mounted round downlight led 22v

15w surface mounted round downlight led 22v



15w surface mounted round downlight led 22v





15w surface mounted round downlight led 22v



Our service·

Your inquiry related to our products or prices will be replied in 24hours.
·Well-trained and experienced staffs to answer all your inquiries in fluent English.
·Any your customized lightings we can help you to design and put into product.
·Monthly output over10000pcs.
·Single package in blister or color-box.
·Sample order in small quantity is acceptable.

Why choose ALLRED?

Fast delivery.As well as other equipment for production and testing to ensure fast delivery for our customers.

Good communication. All our sales stuff are above CET6 grade English level language skills.

Well-trained sales team.We have a group of many sales, who can give you best service with good communication with different department who are operate for the order.

Strong Research ability. Our professional researching team who have the ability to develop new products to satisfy the changing market.

Company pricinple: Offer customer LED lights with competitive price. We are sensitive to price and quality too as you do.
