High Voltage Composite Suspension Insulator / Polymer Suspension Isolator
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Smico
Model Number:
FXBW
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SMICO Goods In Stock 36KV High Voltage Electrical Insulators For Electrical FencingUS$ 0.9 - 9.99MOQ: 100 Pieces -
SMICO 2016 Top Selling Products Bus Bar Composite Suspension Insulator In 36kvUS$ 0.9 - 9.99MOQ: 100 Pieces
-
SMICO Factories Wenzhou Overhead Glass Suspension Insulator High VoltageUS$ 0.9 - 9.99MOQ: 100 Pieces
-
SMICO Interesting Products 2016 33Kv Suspension Polymer Post InsulatorUS$ 0.9 - 9.99MOQ: 100 Pieces
-
SMICO Goods On Sale OEM Welcomed 24KV Medium Voltage Composite Pin InsulatorUS$ 0.9 - 9.99MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
Smico
Model Number
FXBW
Type
Insulator
Material
Other, Polymer
Application
Other, High Voltage, High Voltage
Rated Voltage
12~500KV
Tensile Strength
70-160KN
Introduction
Composite Suspension Insulator is composed of fiberglass epoxy resin lead-out rod, silicon rubber housing and hardware.
It is special for badly polluted areas, high mechanical tension load, long span and compact power line.
Features
1.with excellent electrical characteristics, small volume and less weight.
2. With reliable structure, cannot damage the core rod, and take full advantage of the mechanical strength.
3.With strength wrest resistance and strong explosion protection
Materials
1) Shed: Silicon Rubber
2) Core rod: Glass-fiber reinforced epoxy resin
3) Metal fittings : Hop dip galvanized stainless steel
Main technical parameters:
