Digital angle sensor electronic angle indicator
JD-180 Angle Sensor by potentiometer or pendulum composition, can install in crane booms, bridges.according to the ground Angle is driven by a heavy hammer rotation to determination, the output potentiometer corresponding voltage values.
Please take a look at the following main technical parameters :
1, model: JD - 180 - R (right mounting type) JD - 180 - L (left mounting type)
2, used components: the electrically conductive plastic potentiometer (CPP)
3, measurement range: - 10 ° ~ + 110 °
4 and rated output: DC 3 ~ 6.9 V / 0 ~ 90 °
5, linearity: 0.1, 0.5, 1 percent
6, working voltage: DC15V
7, use temperature scope: - 20 °C ~ + 60 °C
8, use environment humidity: 10 ~ 95%
9, excellent resistance to impact: 20G 15 ~ 20ms
10, resistance to water: waterproof model
Welcome to visit us!
Yichang WTAU Electronic Equipment Co. Ltd is a national high-tech enterprise which located in the “Hydropower capital”— Yichang. WTAU is committed to researching , developing and producing safety devices for crane cranes , automatic monitoring control systems , etc. WTAU puts the principle “make sure the lifting equipments are operated safely and reliably” as our duty and takes the high-tech as the core. WTAU has awarded many patents and major achievements of science and technology. The Torque Limiter, Weight Limiter, Anemometer ,etc. which are researched independently are widely used in electrical, chemical, steel, metallurgy, construction, ports, shipping and other industries.
ANY REQUESTS,PLEASE FEEL FREE TO CONTACT US.
