Initially, wood chipping was mainly used for the efficient removal of branches and green waste in areas such as parks and woodland, but as wood chip came to be regarded as an important natural resource, wood chipping has taken on a new, economic dimension. Wood chip is valuable if the quality is consistent and meets designated requirements. Large quantities of wood chip are already being used as a fuel supply for energy and heating, and for industrial purposes such as MDF board and paper production. In addition, wood chip is extensively used as ground cover or as surfacing material for paths as an environment-friendly weed killer, which reduces or eliminates the need for chemical sprays.
Blades
Two knives made of hardened chipper steel,98*215*10mm double edged,Knives are located in fully machined pockets and are reversible and resharpenable
Knives
Two knives made of 45# steel after quenching, 98*215*10mm double edged,Knives are located in fully machined pockets and are reversible and resharpenable
Engine Model | B&S, 13HP. |
Capacity/Infeed | |
Capacity | 100mm(4inch) |
Infeed chute | 550mm*340mm*440m |
Infeed opening | 210mm*180mm |
Infeed height | 1500mm |
Discharge height | 2200mm |
Discharge chute | Full 360 degree rotation -easy swing/pin locking |
Chipper Disc Housing | |
Disc size | 600mm*25mm |
Disc Weight | 86kg |
Disc Speed | 1430rpm |
Bearing | insert bearing with housing |
Shaft | 55mm 45# steel |
Anvil | Made from 45# steel with four usable sides.Easy external adjustment |
Chipper housing | 5mm plate top and bottom,front and back are:8mm and 6mm |
Fan Paddles | Four fan paddles are bolted on to disc |
For all our machines, we offer one year or 1000 working hours warranty, within warranty, we’ll send all relative parts by express postage, you can receive it in 4~5 days.
