Agricultural machine small telescopic boom wheel loader
boom loader
Easy to handle
TAIAN’s drive-train is operated using a direction pedal that enables the machine to react quickly and with great precision. A foot throttle is found on all TAIAN DY loaders, with which it's possible to maintain the engine speed at the level required for the job, resulting in good fuel economy and noise reduction.
For jobs using attachments that require a continuously high oil flow, such as lawn mowers, brushes, and cultivators, there's a hand leveler. The drive speed can continually be changed, despite the engine speed being held constant.
Both the external hydraulics and the telescopic extension lifting boom are optional controlled using buttons on the joystick, resulting in optimal comfort and efficiency. The operator, therefore, doesn't need to let go of either steering wheel or joystick, and is able to pay full attention to the work being performed.
boom loader
ROPS Cabin or canopy can protect the driver in any case if there’s a tilt danger.
Top rotating warning light give an eye-catching signals to people around.
Warning signals for maintenance and operating protect the machine from over-use.
Reversing beeper and lights, traffic lights, rear and front working lights well protects people around and also the operator.
Cylinder protection can prevent any possible damage caused by the boom falling down.
Thanks to the front articulated design, it greatly reduce the tilt possibility.
Model |
DY840 |
Max. length |
2600mm |
Max. width |
1240mm |
| Max. height | 2330mm |
| Rated loading capacity | 850kg |
| Max. loading capacity | 1250 kgs |
Bucket capacity |
0.45 cbm |
Turning angle |
450 |
Speed |
12 km/h |
Weight without counterweight |
1600kgs |
Standard tire |
26X12-12 |
Tire pressure |
2.8 bar |
Oil tank capacity |
40L |
Pressure |
190 bar |
Oil model(mineral oil) |
L-HL46 |
Number of cylinder |
4 |
Cooling systerm |
Waer cooling |
Rated power |
24.5 Kw |
Rotation speed |
2800 r/min |
Fuel tank capacity |
23L |
Battery capacity |
60 Ah |
Voltage |
12V |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
