Chinese high quality small skid steer loader
skid steer loader
TAIAN MS500 Mini Track Loader gives you the power to tackle big jobs in close quarters with impressive traction and lifting abilities. It turns quickly in its tracks, and treads lightly over soft ground and lawns. With a big range of attachments, it gives you endless work-saving opportunities. Used by itself or in combination with bigger loaders, this mini track loader is a maxi work-saver.
skid steer loader Model |
MS500 |
Moving type |
Track or Wheel |
Max. Length (without bucket) |
1760 mm |
Max. width |
1100 mm |
Max. height |
1295 mm |
Speed |
5km/h |
Rated loading capacity |
520kg (including attachment) |
Tipping load |
1040kg |
Max. reach |
1800mm |
Tyre |
6.50-10 |
Tyre pressure |
790Mpa |
Pushing power |
8.2KN |
Weight (without attachment) |
900kg (Wheel type) |
1005kgs (Track type) | |
Hydraulic oil flow |
30L/min |
Track oil flow |
46L/min |
Oil tank capacity |
38L |
Oil mode |
L-HL46 |
Gasoline oil capacity |
28L/min |
Battery capacity |
45Ah |
Voltage |
12v |
Engine |
Kohler CH752, 27HP |
Engine type |
Gasoline, 2 cylinder, Air cooling |
Rotation speed |
3600r/min |
Optional Chinese Diesel Engine | |
Engine model |
Changchai 3M78, 21.76HP |
Engine type |
Diesel, 3 cylinders, water cooled |
Engine speed |
3000r/min |
Machine Size(LxWxH/mm) without bucket |
1910mmx1150mmx1345mm |
Weight (without attachment) |
1240KG |
| |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
