pile driver with quick coupling of hammer or screw driving head
pile driver
1.For solar station
2.Large torque
3.Super quality engine
4.Four wheel drive
5.easy to operate and maintain
6.excellent working performance
7.Easily operation
8.Adjustable spring seat
9.For the solar system
10.high efficiency
11.Joystick control
12.different screw driving unit
13.Wide view cabin
14.Unique and new design
15.based on wheel loader
16.electrical gear shift with combined joystick
17. Axle with hub reducer
18.Rotating warning light on top.
19.Reverse camera
20. A/C available
pile driver
1. It has two different kinds of driving unit, one is for ground screws which is turning type, another one is for ground posts which likes hammer. With these two driving units can suits different working requirement.
2. Rock breaker is available as an option, can be used for hard, rought terrian.
3. The machine body adopts 4 wheel drive, and two speed, which is smart and increase the efficiency.
4. Machine is equiped with angle guage, which helps the operator adjust the direction in time and guarteen vertical drilling.
5. Besides all the advantages above, compared with other similiar machines, we offer very competitive prices and best service to customers. To achieve biggest purchasing safisfaction is always our persue.
Model |
PD3000 |
Max. Length |
4370mm |
Max. width (mm) |
1850mm |
Max. height (mm) |
3450mm |
Turning angle |
320 |
Speed |
17km/h |
Weight |
4560kg |
Standard Tyre |
20.5-16 |
Tyre pressure bar |
2.8 bar |
Oil tank capacity |
40 L |
System pressure |
190bar |
Rod diameter |
76-90 mm |
Max. Drilling depth |
3000mm |
Oil model |
L-HL46 |
Engine |
Yunnei 4102 |
Cooling system |
Water cooled |
Rated power |
60kw |
Rotating speed |
2400 r/min |
Fuel tank capacity |
40 L |
Battery |
105AhX2 |
Voltage |
24 V |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
