impact stregth high quality wear resistance UHMWPE sheet supplier
Introduction
UHMW-PE defined is Ultra High Molecular Weight Polyethylene. UHMW-PE is a polyethylene with a molecular weight of 4.5 – 6 million. It is this high molecular weight that gives UHMW-PE its unsurpassed combination of slickness, toughness and chemical resistance. We uses 100 % virgin UHMW-PE in every product manufactured.
The properties of UHMW-PE:
Property | Unit | Value |
Density | g/cm3 | 0.93-0.96 |
Average molecular weight | g/mol | 3million- 10 million |
Tensile strength (23°C in air) | MPa | 22 |
Breaking strength | MPa | 42 |
Tensile strain at break | % | 600 |
Charpy impact strength (notched) | mJ/mm2 | No break |
Ball indentation hardness | N/mm2 | 42 |
Shore D hardness | -- | 65-70 |
Abrasion | % | 70-80, steel = 100 |
Static Friction Coefficient | -- |
≤0.16 |
Kinetic Friction Coefficient | -- |
≤0.10 |
Water Absorption | -- | NIL |
Elongation at break at 23 degress | % | ≥300 |
Temperature resistance | °C | -269 to +85 |
Melt Temperature | °C | 130-140 |
UHMWPE Advantages & Key Features:
--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
--Anti-Weather & Anti-Aging
--Self-lubricating, Very low coefficient of friction
--Excellent chemical & corrosion resistant
--superior impact resistant, Noise- absorption, Vibration-absorption
--High tensile Strength
--Non-Toxic and smell
--UV resistance
--Flame Retardant; Relatively low in water absorption
--Excellent electrical properties
--Good performance in resisting environment stress crack, 200 times of ordinary PE
--No adhesion
--Cost efficient; Resulting in low energy consumption
UHMWPE properties:
Excellent impact resistance
High mechanical strength
Resistant to many solvents
Excellent chemical and corrosion resistance
Very high damping properties
Temperature resistance from -200C to +80C
Minimum water absorption (0.01%)
Extremely low co-efficient of friction
Self lubricating
7 times lighter than steel
3 times lighter than aluminun
impact stregth high quality wear resistance UHMWPE sheet supplier
Our UHMW-PE sheet standard sizes:
1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:
Length(mm) | Width(mm) | Thickness(mm) |
2000 | 1000 | 6-300 |
3000 | 1500 | 6-300 |
4700 | 1200 | 6-300 |
5000 | 1300 | 6-300 |
4500 | 2000 | 6-300 |
3050 | 1220 | 6-100 |
Any small size need us to cut , we can satisfy your special need .
Shandong Ningjin Xinxing Chemical Co.,Ltd. is one of the largest Engineering Plastic products manufacture in China.
All the stuff in our company are dedicated to producing satisfying products and developing new products for our customer.
We have gained many certificates from government and professional fields .We have a wide variety of products,
mainly including all kinds of UHMWPE Fender Pad ,UHMWPE Sheet ,HDPE Sheet ,PP Sheet ,PVC sheet and other
Engineering plastic products.
Our products are widely applied on electric fields ,wharf and port ,mining ,chemical plant and so on which bring a lot of
social benefits and economic benefits .Now they are popular all over the world.
We always share the things "Quality first, Customer first ,keeping improving " to win more benefits for our customer.
In order to achieving rapid and sustainable development, we are willing to establish a wide and deep cooperation relation
with enterprises both home and abroad.
Q:Are you a manufacturer or a trading company?
A:We're one of the leading PE manufacturer in China for more than 20 years.
Q:Is sample available?
A:Yes.The sample is free,but you should pay the freight charge.
Q:Is the size fixed?
A:No.we can meet your needs according to your requirement. That is to say, we accept to customize.
Q: Is it all right to make customer's own brand name?
A: That’s all right to engrave your own brand name.
Q. Can you special order a product for me?
A. We are typically able to special order products for customers. OEM service.
impact stregth high quality wear resistance UHMWPE sheet supplier
Any details pls contact me~
