5M Hydraulic NC servo press machine with CE Safety Standards

Name: 5M Hydraulic NC servo press machine with CE Safety Standards
Brand: AccurL
Availability: InStock

FOB Price

US$ 32,500 - 37,500 / Set

1 Set(Min. Order)

Port ShangHai Port China
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Anhui, China
Brand Name	AccurL	Model Number	WC67K 250T/5000
Machine Type	Press Brake	Raw Material	Sheet / Plate Rolling
Material / Metal Processed	Stainless Steel	Power	Other, Hydraulic, 18..5kw
Automation	Automatic	Extra Services	Machining
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Company Information

Factory Information:

Manufacturers : ANHUI LAIFU NC MACHINE TOOL CO.,LTD

Brand : ACCURL

Machine: Shearing Machine,Hydraulic Guillotine Hydraulic Guillotine,CNC Press Brake and Hydraulic Press.

Address:Bowang District Bowang Equipment Industrial Park,Ma’anShan Anhui China

Tel: +86-555-2780553 Fax: +86-555-2780563 Phone: +86-13335550823( WhatsApp )

E-M-A-I-L: Info(at) Ahlaifu(at)

Website:

YouTube Videos:

1. China E21 NC Press Brake : https://youtu.be/kRv_7A84kDI

2. DA41 CNC Press Brake : https://youtu.be/rrl_dOxjfNA

3. CNC 3 axis Press Brake : https://youtu.be/E6ISsGyCaYY

4. E21 NC Shearing Machine : https://youtu.be/Qc8WEhYE0-M

5. Hydraulic Guillotine Shears : https://youtu.be/gfK0waenqEs

6.CNC Laser Cutting Machine : http://youtu.be/Nz6yomUC1Ug

whole structure of the hydraulic press brake:

1.Totally European design, streamlined looking,Monoblock,Welded steel frame rigid to deflection moment and high tensile with ST44 A1 material.

2.AccruL PRESS BRAKE incorporates ESTUN E10 NC controls offer not only failsafe operation of the vital operations of the machine,but also offer the operator considerable assistance in carrying out the entire bending process.

3.High accuracy,high efficiency,simple and convenient operation,good performance, favorable price and best service.

1. Hydraulic system:

1. Adopt integrated hydraulic control system, more reliable and easy for maintenance.Hydraulic system is from Bosch – Rexroth,Germany.

2.Extremely reliable and precise Bosch – Rexroth valves are used for the regulating circuit. Every complete working cycle can be achieved through the control of hydraulic valve.

3.Overload overflow protection is outfitted to hydraulic system,which can assure no leakage,and the oil level can be read or seen directly.

Being able to work under rated load continuously,stable working and high precision.

4 All seals in cylinder is PARKER from USA,the most famous brand,good quality and high performance

2. Electrical system and the safety interlock:

1.Electrical panel with cooling system designed to meet CE Standards and composed of automation and electrical equipments with SIEMENS brand.

2.Protective fence and the safety interlock to ensure the operation safety. Have a movable single-hand pedal switch,easy to operate.

3.Front Side Covers with safety switches, Back light safety guards (Category-4),Foot pedal conforming to CE regulation.

4. The machine by the European Union CE certification and ISO quality system certification

3. Synchro control system:

1. Slide synchro system:adopt steel torsion bar synchro system, simple in structure and high in accuracy,ensures the parallelism between beams is used for the synchronism

2. ends of slide has 2 synchro fork which make,The system uses upper die compensation to improve the brake precision.

3.The worktable adopts the particular design,reducing the crowning distortion amount of lower tool effectively.

4. Ram Structure and Bending precision:

1. The bending accuracy and consistency of the repeatability are achieved by a simple mechanical system of adjustable depth Automatic (digit readout) and motorized (Estun E10 NC Control) Adjustable.

2. Can move the ram up slowly,which allows the operator to control work piece conveniently.

3. Universal fixing-surface of the upper tool can be meeting with the clamping requirement of the tool farthest.

4. Hardened and ground standard sectioned top and 4V-Die bottom tools (4x1000 mm sections).

5. Motorized Backgauge (Standard)

1. CNC Back gauge system with X axis by AC servo motor driven ball screw shafts and on linear bearings with an accuracy of 0.01mm.

2. Back gauge has well enough mechanical strength and rigidity with tank-type gauge structure.

3. High-precision ball screw and linear guide-way.Particular finger-stop design,enlarge the range of back gauge

The whole stcture ofthe hydraulic press brak
