black color UHMWPE stand pipe support
UHMWPE material has exceptionally low coefficient of friction offering superb sliding properties and is one of the best plastics for wear/abrasion resistance meanwhile tough and impact resistant even at cryogenic temperatures. As a result, it is definite that UHMW polyethylene is a wonderful engineering plastic that can solve many problems that other engineering plastics cannot.
Characters of pipe clamp support block
Extremely high anti-abrasion;
Excellent self-lubricating performance;
Good in resisting impact, flexibility;
Being excellent in resisting chemical corrosion(acid, alkali, salt);
Being free from toxin, smell or exudates;
Good electric resistance;
Low in water absorption;
Low coefficient of friction;
Resisting environment and anti-aging;
Resisting high and low temperature;
UV resistance
The properties of UHMW-PE:
Property |
Unit |
Value |
Density |
g/cm3 |
0.93-0.96 |
Average molecular weight |
g/mol |
3million- 10 million |
Tensile strength (23°C in air) |
MPa |
22 |
Breaking strength |
MPa |
42 |
Tensile strain at break |
% |
600 |
Charpy impact strength (notched) |
mJ/mm2 |
No break |
Ball indentation hardness |
N/mm2 |
42 |
Shore D hardness |
-- |
65-70 |
Abrasion |
% |
70-80, steel = 100 |
Static Friction Coefficient |
-- |
≤0.16 |
Kinetic Friction Coefficient |
-- |
≤0.10 |
Water Absorption |
-- |
NIL |
Elongation at break at 23 degress |
% |
≥300 |
Temperature resistance |
°C |
-269℃ to +85℃ |
Melt Temperature |
°C |
130℃-140℃ |
2.Advantage of UHMWPE pipe support block/ pipe support block/pipe support:
- UHMW exhibits virtually no water absorption
- Non-Toxic
- Low coefficient of friction
- Corrosion resistant
- Abrasion and impact resistant
- Wear Resistant
- Dielectric
- Weatherproof
3.The application of uhmwpe pipe support blocks :
- Textile Industry:
- Chemical Industry:
- Food Processing Industry:
- Paper Industry:
- Material Handling:
- Farm Implement:
- Mining & Metals Processing Industries:
- Transportation:
- Consumer Products:
- Waste Water Treatment:
- uhmwpe pipe support block for decoration
4.Our UHMW-PE machined parts Characters:
1.very flat on the surface
2.The thickness tolerance is +2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.
5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.
6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.
5.Our Other Plastic Products:
Engineering plastic;
UHMW-PE Sheet; HDPE Sheet; PE Sheets;UHMW-PE/HDPE/PE Machined Parts;
Synthetic ice rink board, artificial ice rink, portable hockey training board;
UHMW-PE/HDPE Marine fender board;
UHMW-PE/HDPE Outrigger pad;
UHMW-PE/HDPE Liner board;
UHMWPE guide rail/uhmwpe wear strips;
And other uhmwpe and hdpe products, welcome to ask!
Packaging : pallet packing or as client need.
6.Why Choose Us
--More than 15 years' professional manufacturing experience with own factory
--Virgin 100% material produced, high quality with good surface and color make ensured
--GB/T 19001-2008 ; ISO 9001:2008 certification.
--Competitive price, In stock, Fast delivery, and Excellent service.
--OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.
welcome to visit our factory!
