ASA Synthetic Resin Tile

Name: ASA Synthetic Resin Tile
Brand: Guoxiang
SKU: 129013709
Availability: InStock

US$ 6 - 9 MOQ: 100 Square Meters

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Guoxiang

Model Number:

classic 720

Jiangsu Guoxiang Building Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Lianyungang Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Guoxiang

Model Number classic 720

SYNTHETIC RESIN TILE

Product Detail

ASA&PMMA synthetic resin tile plate, the advantages are as belows:

Corrosion resistance;

Color stable;

Sound absorption and heat insulation;

Good water resistance;

Fireproof resistance;

Easy to install;

Good impact and low temperature resistance;

Light weight;

Stable volume;

Environment friendly and easy saving.

Technical Data for ASA&PMMA synthetic resin tiles

Item	Content	Result	Standard
1	Appearance	Smooth surface, uniformity of thickness, no crack or other defect	GB/T 8814-2004
2	Density	1.648 g/m3	GB/T 1033.1-2008
3	Bending strength	48.2 Mpa	GB/T 9341-2008
4	Flexural modulus	2.70 Gpa	GB/T 9341-2008
5	Tensile yield stress	26.3 Mpa	GB/T 1040.2-2006
6	Tensile fracture strain	26 %	GB/T 1040.2-2006
7	Freeze-resistance properties (circulate 10 times)	Surface has no crack, hollowing, blister or stripping	JG 149-2003
8	Falling ball impact test at low temperature (damage number / impact number) (-10℃, 1m, 1.0kg)	0 / 10 piece	GB/T 8814-2004
9	Thickness	3.04 mm (we have 3 kinds of thickness: 2mm, 2.5mm and 3mm)	GB/T 8814-2004
10	Appearance when heated to 150℃	No bubble, crack or hard spot	GB/T 8814-2004
11	Dimension change rate	1.29 %	GB/T 8814-2004
12	Co-extrusion layer thickness	0.18 mm	GB/T 2976-2008
13	Vicat softening temperature (B50)	80.2 ℃	GB/T 1633-2000
14	Wind load	2.0 Kpa	GB/T 7106-2002
15	Hard to burn	B1 grade Oxygen index: 32.5	GB/T 2406-1993
16	Vertical Burning	FV-0	GB/T 2408-1996
17	Horizontal burning	FH-1	GB/T 2408-1996
