Brightly Colored Roof Tiles

Name: Brightly Colored Roof Tiles
Brand: Guoxiang
SKU: 129011209
Availability: InStock

US$ 7 - 8 MOQ: 100 Meters

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Guoxiang

Model Number:

940

Jiangsu Guoxiang Building Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Lianyungang Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Guoxiang

Model Number 940

Product Detail

ASA&PMMA synthetic resin tile plate, the advantages as belows:

1. Corrosion resistance;

2. Color stable;

3. Sound absorption and heat insulation;

4. Good water resistance;

5. Fireprood resistance;

6. Easy to install;

7. Good impact and low temperature resistance;

8. Loght weight;

9. Stable volume;

10. Environment friendly and energy saving.

Technical Data for ASA&PMMA synthetic resin tiles

Item	Content	Result	Standard
1	Appearance	Smooth surface, uniformity of thickness, no crack or other defect.	GB/T 8814-2004
2	Density g/cm3	1.648	GB/T 1033.1-2008
3	Bending strength MPa	48.2	GB/T 9341-2008
4	Flexural modulus GPa	2.70	GB/T 9341-2008
5	Tensile yield stress MPa	26.3	GB/T 1040.2-2006
6	Tensile fracture strain %	26	GB/T 1040.2-2006
7	Freeze-resistance properties (circulate 10 times)	surface has no crack, hollowing, blister or stripping.	JG 149-2003
8	Falling ball impact test at low temperature (damage number/impact number) (-10℃, 1m, 1.0kg) piece	0/10	GB/T 8814-2004
9	Thickness mm	3.04	QB/T 8814-2004
10	Appearance when heated to 150℃	No bubble, crack or hard spot	GB/T 8814-2004
11	Dimension change rate %	1.29	GB/T 8814-2004
12	Co-extrusion layer thickness mm	0.18	GB/T 2976-2008
13	Vicat softening temperature (B50) ℃	80.2	GB/T 1633-2000
14	Wind load KPa	2.0	GB/T 7106-2002
15	Hard to burn	B1 grade Oxygen index: 32.5	GB/T 2406-1993
16	Vertical burning	FV-0	GB/T 2408-1996
17	Horizontal burning	FH-1	GB/T 2408-1996
