High quality non-stick self-lubricating uhmw plate for resisting liner for truck
Why Choose Us
l More than 15 years' professional manufacturing experience with own factory.
l Virgin 100% material produced, high quality with good surface and color make ensured
l GB/T 19001-2008 ; ISO 9001:2008 certification.
l Competitive price, In stock, Fast delivery, and Excellent service.
l OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.
WHAT IS UHMW-PE?
UHMW-PE defined is Ultra High Molecular Weight Polyethylene. UHMW-PE is a polyethylene with a molecular weight of 4.5 – 6 million. It is this high molecular weight that gives UHMW-PE its unsurpassed combination of slickness, toughness and chemical resistance. We uses 100 % virgin UHMW-PE in every product manufactured.
UHMWPE can be supplied in Sheet & Rod
UHMWPE properties
- Excellent impact resistance
- High mechanical strength
- Resistant to many solvents
- Excellent chemical and corrosion resistance
- Very high damping properties
- Temperature resistance from -200C to +80C
- Minimum water absorption (0.01%)
- Extremely low co-efficient of friction
- Extremely low co-efficient of friction
- Self lubricating
- 7 times lighter than steel
- 3 times lighter than aluminun
The properties of UHMW-PE:
Property |
Unit |
Value |
Density |
g/cm3 |
0.93-0.96 |
Average molecular weight |
g/mol |
3million- 10 million |
Tensile strength (23°C in air) |
MPa |
22 |
Breaking strength |
MPa |
42 |
Tensile strain at break |
% |
600 |
Charpy impact strength (notched) |
mJ/mm2 |
No break |
Ball indentation hardness |
N/mm2 |
42 |
Shore D hardness |
-- |
65-70 |
Abrasion |
% |
70-80, steel = 100 |
Static Friction Coefficient |
-- |
≤0.16 |
Kinetic Friction Coefficient |
-- |
≤0.10 |
Water Absorption |
-- |
NIL |
Elongation at break at 23 degress |
% |
≥300 |
Temperature resistance |
°C |
-269 to +85 |
Melt Temperature |
°C |
130-140 |
UHMWPE Advantages & Key Features:
--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
--Anti-Weather & Anti-Aging
--Self-lubricating, Very low coefficient of friction
--Excellent chemical & corrosion resistant
--superior impact resistant, Noise- absorption, Vibration-absorption
--High tensile Strength
--Non-Toxic and smell
--UV resistance
--Flame Retardant; Relatively low in water absorption
--Excellent electrical properties
--Good performance in resisting environment stress crack, 200 times of ordinary PE
--No adhesion
--Cost efficient; Resulting in low energy consumption
High quality non-stick self-lubricating uhmw plate for resisting liner for truck
Our UHMW-PE sheet standard sizes:
1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:
Length(mm) |
Width(mm) |
Thickness(mm) |
2000 |
1000 |
6-300 |
3000 |
1500 |
6-300 |
4700 |
1200 |
6-300 |
5000 |
1300 |
6-300 |
4500 |
2000 |
6-300 |
3050 |
1220 |
6-100 |
Any small size need us to cut , we can satisfy your special need .
Established on 1989, we have nearly twenty years experience in making UHMWPE and HDPE products.We develop and manufacture UHMWPE and HDPE products and deliver them to all over 30 countries.Our mainly products is UHMWPE Marine fender pad, UHMWPE Liner,UHMWPE Sheets,UHMWPE Parts and HDPE Sheet and so on.
Our people are dedicated to produce more and more high quality and technique UHMWPE and HDPE products for customer.
We are not a large factory but a most professional one which allow us to strive for quality products,short time delivery, best service at a reasonable price.
Packaging : pallet packing or as client need.
High quality non-stick self-lubricating uhmw plate for resisting liner for truck
Any questions, please feel free to contact me.
Many thanks!
