Home > Construction & Decoration > Decoration Materials > Plastic Sheet, Board & Panel > Virgin 100% PTFE Extruded Rod Manufacture

Virgin 100% PTFE Extruded Rod Manufacture

Name: Virgin 100% PTFE Extruded Rod Manufacture
Brand: XINXING
SKU: 129005379
Availability: InStock

Virgin 100% PTFE Extruded Rod Manufacture thumbnail-1

Virgin 100% PTFE Extruded Rod Manufacture photo-1

US$ 6 - 15 MOQ: 1000 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

XINXING

Model Number:

XXPTFE001

Contact Supplier Request Quote Chat Now

Shandong Ningjin Xinxing Chemical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name XINXING

Model Number XXPTFE001

Material PTFE

Thickness 1-30MM

Size Customized

Specifications

PTFE rod with wear resistance,Good tensile strength, excellent tear elongation, antiweather, anti-temperature, various color

XINXING PTFE rod

There are 3 kinds of PTFE rods. Diameter 4-9 mm rod was made of 100% PTFE by paste extrusion processing; diameter 10-50mm was made by PTFE resin suspended plunger extrusion processing; diameter >50mm is made by molded process.

In the known plastic, PTFE has the most excellent chemical resistance and dielectric performance, non aging, not sticky, wide range of working temperature -180 °C~+260 °C,in known solid material it has minimum friction coefficient.

Specification

Type	Diameter(mm)		Length(mm)
	Nominal	allowed tolerance	Nominal	allowed tolerance
SFFBN	4,5,6	+0.48 0	100	+5.0
	7,8,9	+0.58 0
SF×BN	10,13,15 16,18	+1.10 0	1000	+3.60
	20,25,30	+1.30 0
	35,40,45 50	+1.60 0
	55,60,65,70,75 80,85,90,100	+2.00 0	1000	+2.50
	110,120,130 140,150	+2.50 0
	180,200,250 270,300	+3.0 0	300	+2.0

The Main Technical Indexes

Item	Unit	Result
Apparent density	g/cm3	2.10-2.30
Tensile strength ≥	MPa	14.0
Tear elongation ≥	%	140

Notes: when the diameter ≥ 16 mm, only test the apparent density

Function Electrical insulating parts, sealing gasket, anti adhesion materials

For more questions ,please contact us.

Shandong Ningjin Xinxing Chemical Co.,Ltd

Judy Wang

skype:judyxx2014

Tel:86-534-5222055

Why choose us:

1. More than 15 years professional manufacturing experience with own factory

2. Virgin 100% material produced, high quality with good surface and color make ensured

3. GB/T 19001-2008; ISO9001:2008 certification

4. Competitive price, in stock, fast delivery and excellent service

5.OEM available, special character available, according to different requirement with different application, color, size, shape and special specification can be customized, such as anti- UV, antistatic and so on.
