hdpe rod/uhmwpe rod bars/plastic rod
UHMW-PE advantages:
Because of UHMWPE's low coefficient of friction for example, UHMWPE will decrease the energy needed to operate machinery. The agriculture industry has found that using UHMWPE as opposed to steel in scraper applications realized increased fuel economy, reduced noise levels and increased wear resistance. In material handling, the use of UHMWPE sprockets and bearing surfaces have not only improved overall performance but have extended the life of conveying systems. In food handling systems UHMWPE has eliminated the need for unwanted grease or oil lubricating methods, in fact, UHMW-PE is FDA and USDA approved for direct food contact.
UHMW characteristics
1 Highest abrasion resistance of any polymer
2 Outstanding impact strength
3 Intricate parts
4 Cost efficient
5 Improved performance
6 Self lubricating material
7 Light weight
8 Low Tooling costs
9 Non-Toxic
10 Sound dampening properties
11 Good chemical resistance
Advantage of acrylic products:
1.Excellent transparency 2.Good electrical insulation
3.Stable and Durable 4.Non-toxic
5.superior impact resistance, weather resistance, chemical resistance, crack resistance and UV resistance
6. stable mechanical performance and nice looking
The main characteristics of HDPE (High Density Polyethylene) Grade are:
Very low water absorption
Good sliding properties
Resistant to dilute acids, cleaning agents, numerous solvents
Very good electrical insulation
Difficult to bond
Low density
The preferred field of use for this product are; mechanical engineering, transport and conveyor technology, electrical engineering, general engineering, household appliances, plant construction, and the food industry.
Popular applications for the use of HDPE (High Density Polyethylene) Grade are:
Product Description:
Ultrahigh molecular weight polyethylene rod is a kind of engineering thermoplastic.
It combines superior performance of most plastic, such as impact resistance, low temperature
resistance, wearresistant, chemical resistant, selflubricating and absorbing impact energy.
They are the best till now. And UHMWPE products are widely used in Europe and the United States,
and demanding is growing.
Processing customized according to customers' drawings and actual size.
Features of UHMWPE
Best shock resistance even in low temperature.
Low frictional factor, and well sliding bearing material
Lubricity( no caking, in adhesion)
Best chemical corrosion resistance and stress craze resistance
Excellent machinery process ability
Lowest water absorption(<0.01%)
Paragon electric insulativity and antistatic behavior
Nice high energy radioactive resistance
Abrasive resistance which always have in thermoelectricity polymer.
Density is lower than other thermoplastics (< 1g/m3)
Long using temperature range: -269°C--90°C
Diameter 20mm uhmwpe rod, abrasion resistant uhmwpe rod
colorful uhmw pe plastics rod
food grade uhmwpe rod
HDPE rod, high quality high-density polyethylene HDPE rod
wear resistant White HDPE Rods and bars manufacturer
1,Udated Equipments and modern Machining-Center
Four production lines and more than 15 updated precision processing equipments,
Customized Engineering plastic parts available.
2,Rich experience:
Processional technician and rich experience in engineering plastic field
1.UHMWPE rod (ultra high molecular weight polyethylene rod)
Product name |
UHMWPE rod |
Features |
Self-lubricating. Good Abrasion&wear resistance (15 times more resistant to abrasion than carbon steel). Corrosion & impact resistant. low temperature resistant. Non-water absorption Easy to machine |
Size |
Dia(diameter):20-300mm Length:250mm,500mm,1000mm,etc. * We can also provide any other size as your special need. |
Color |
white,black,red,blue,green,yellow,etc. |
Application |
Application: Replace carbon steel, stainless steel, bronze used in textile, paper making, food machinery, transportation, medical machinery, coal machinery, chemical industry and other departments.
Examples: Technical spindle, picking stick, gear, coupling, flower stem, buffer block, eccentric block, rod bushing and other wear resistant parts in textile industry. Besides, owing to its wear resistant is better than carbon steel, it can be shaped various different parts for machinery, including the gear in food machinery, worm gear, worm, bearing etc. |
Property data sheet of HDPE/UHMWPE rod:
Item |
Test method |
Test result |
unit |
Specific weight |
ASTM D-792 |
0.96 |
g/cm3 |
Yield strength |
ASTM D-638 |
25 |
MPa |
Ultimate strength |
ASTM D-638 |
45 |
MPa |
Breaking Elongation |
ISO527 |
355 |
% |
Impact strength |
ISO179 |
130 |
Mj/mm2 |
Abrasion |
ISO15527 |
83 |
Steel=100 |
Shore Hardness |
ISO868 |
65 |
Shore D |
Friction Coefficient |
ASTM D-1894 |
0.11 |
Unitless |
Coefficient of thermal expansion |
ASTM D-696 |
0.0002 |
℃ |
Volume resistifity |
IEC600093 |
≤1000 |
∩*cm |
Surface resistifity |
IEC600093 |
≤1000 |
∩ |
Water Absorption |
ASTM D-570 |
0.0094 |
% |
Melt point |
ASTM D-3417 |
138 |
℃ |
1,Updated Equipments and modern Machining-Center
Four production lines and more than 15 updated precision processing equipments,
Customized Engineering plastic parts available.
2,Rich experience:
Processional technician and rich experience in engineering plastic field
3,High products quality
Stable raw material and independent material test center to ensure the quality
4,Low products price with high productivity
5,Low transportation cost ,near Qingdao port and Xingang Port
6,Qualified manufacturer:
ISO9001:2008 approved
Extablished Company-standard for our products
Qualified exporter without products problem since company established
High-integrity enterprise verified by Industrial and Commercial Bureau
1.Extremly high anti-abrasion:Owing to its particular molecular structure,anti-abrasion performance of UHMW-PE is high than ordinary metal and plastic:6.6 times of carbon steel,5.5times of stainless steel,27.3 times of brass,6 times of nylon and 5 times of PTFE.
2.Excellent self-lubricating performance,being low in friction coefficient and flow resistance,resulting in low energy consumption.
3.Good in resisting impact,flexibility.Even under low temperature and thunder impact,it does not break.
4.Being excellent in resisting chemical corrosion:it woks against all acid,alkali,salt mediumexceptconcentrated sulfuric acid,dense nitric acid and some porganic solvent.
6.Good electric resistance,ralatively low in water absorption.
7.Good performance in resisting enxironment stress crack,200 times of ordinary PE.
8.Excellence in withstanding low temperature.it doesn't become fragile even under -180°C surronding temperature.
Advantages:
1) Very low coefficient of friction
2) High toughness (also at low temperature)
3) High elongation
4) Very good electrical and dielectric properties
5) Very low water absorption
7) Good protection against stress cracking
8) Resistance to abrasion
9) Economical engineering plastic
10) Food safety.
