High quality good abrasion resistant uhmwpe rod,HDPE rod, high quality high-density polyethylene HDPE rod
abrasion resistant uhmwpe rod
abrasion resistant hdpe, uhmwpe, and pp rod
High quality good abrasion resistant uhmwpe rod
HDPE rod, high quality high-density polyethylene HDPE rod
HDPE rod, UHMW Natural Round Rod
HDPE rod, UHMWPE Rod, nylon rod
wear resistant White HDPE Rods and bars manufacturer
For sale wear resistant White HDPE Rods and bars
1.Application:
It can be used as anti-erode machines components, available for wire and cable insulation
material of high frequency insulation and high voltage insulation, soundproof material for air-conditioner, cushion material of packing industry, food machine, water-sports material. The density is 0.954g/cm3.
--Chain and belt guides
--Sliding and power transmission components
--Chain sprockets and gear wheels
--Sliding components and bearings
--Track and guide rollers
2.specification:
diameter:15mm-300mm
size:1000,2000mm or as order.
3.Technology parameters:
Item |
Density |
Tensile strength |
vicatsoftening temperature: |
Unit |
g/cm |
Mpa |
oC |
Target |
0.919-0.925 |
>25 |
>90 |
4. Key Features and Benefits Of PE Rod
RoHS & REACH compliant ,Stain resistant ,Lightweight , Grafitti resistant ,Moisture resistant ,Low coefficient of friction ,Durable ,Odor resistant ,Abrasion resistant ,Easily fabricated ,Chemical resistant ,High impact strength ,Weldable/Bendable - suitable for fabrication, UV Resistant - Black only, Physiologically inert - approved for food applications (Natural only), Electrical insulation - it is a good insulator, Weatherproof - it doesn't absorb water, Chemical resistance - resists corrosive chemical
1.UHMWPE rod (ultra high molecular weight polyethylene rod)
Product name |
UHMWPE rod |
Features |
Self-lubricating. Good Abrasion&wear resistance (15 times more resistant to abrasion than carbon steel). Corrosion & impact resistant. low temperature resistant. Non-water absorption Easy to machine |
Size |
Dia(diameter):20-300mm Length:250mm,500mm,1000mm,etc. * We can also provide any other size as your special need. |
Color |
white,black,red,blue,green,yellow,etc. |
Application |
Application: Replace carbon steel, stainless steel, bronze used in textile, paper making, food machinery, transportation, medical machinery, coal machinery, chemical industry and other departments.
Examples: Technical spindle, picking stick, gear, coupling, flower stem, buffer block, eccentric block, rod bushing and other wear resistant parts in textile industry. Besides, owing to its wear resistant is better than carbon steel, it can be shaped various different parts for machinery, including the gear in food machinery, worm gear, worm, bearing etc. |
Property data sheet of HDPE/UHMWPE rod:
Item |
Test method |
Test result |
unit |
Specific weight |
ASTM D-792 |
0.96 |
g/cm3 |
Yield strength |
ASTM D-638 |
25 |
MPa |
Ultimate strength |
ASTM D-638 |
45 |
MPa |
Breaking Elongation |
ISO527 |
355 |
% |
Impact strength |
ISO179 |
130 |
Mj/mm2 |
Abrasion |
ISO15527 |
83 |
Steel=100 |
Shore Hardness |
ISO868 |
65 |
Shore D |
Friction Coefficient |
ASTM D-1894 |
0.11 |
Unitless |
Coefficient of thermal expansion |
ASTM D-696 |
0.0002 |
℃ |
Volume resistifity |
IEC600093 |
≤1000 |
∩*cm |
Surface resistifity |
IEC600093 |
≤1000 |
∩ |
Water Absorption |
ASTM D-570 |
0.0094 |
% |
Melt point |
ASTM D-3417 |
138 |
℃ |
2. HDPE rod (high density polyethylene rod)
Product name |
HDPE rod |
Features |
Self-lubricating. Lightweight Durable Corrosion & impact resistant. Great weather resistance Easy to weld but difficult to bond. Easily fabricated |
Size |
Dia(diameter):10-480mm Length:250mm,500mm,1000mm,etc. * We can also provide any other size as your special need. |
Color |
white,black,red,blue,green,yellow,etc. |
Application |
Application: Replace carbon steel, stainless steel, bronze used in textile, paper making, food machinery, transportation, medical machinery, coal machinery, chemical industry and other departments.
Examples: Technical spindle, picking stick, gear, coupling, flower stem, buffer block, eccentric block, rod bushing and other wear resistant parts in textile industry. Besides, owing to its wear resistant is better than carbon steel, it can be shaped various different parts for machinery, including the gear in food machinery, worm gear, worm, bearing etc. |
Property data sheet of HDPE rod
Property |
Testing Method |
Value |
Molecular Weight 1E6 g/mol |
ASTM D6474 |
1-3 |
Density g/cm³ |
ISO 1183-1 |
0.94-0.98 |
Abrasion % |
ISO15527 |
100 |
Dynamic coefficient of friction |
ISO8295 |
≤0.15 |
Shore hardness |
ISO868 |
≥63 |
Water absorption % |
ASTM D-570 |
≤0.1 |
Temperature resistance 0C |
|
-200 to +80 |
Elongation at break at 23 degree % |
ISO 527 |
≥200 |
Melt Temperature 0C |
|
130-140 |
