34W 1560mm 2ft CE ROHS Led Vaporproof Lights for Production Workshop

34W 1560mm 2ft CE ROHS Led Vaporproof Lights for Production Workshop thumbnail-1
34W 1560mm 2ft CE ROHS Led Vaporproof Lights for Production Workshop photo-1
US$ 20 - 100 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
Osram
Warranty(Years):
5
Input Voltage(V):
100-240/270
Contact Supplier Request Quote Chat Now
Cixi Yuanhui Lighting Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Osram
Warranty(Years) 5
Input Voltage(V) 100-240/270
Lamp Power(W) 34
Lamp Luminous Flux(lm) 3030
Lamp Luminous Efficiency(lm/w) 95
Color Temperature(CCT) Cool White
Working Temperature(℃) -35, 45
Working Lifetime(Hour) 50000
Lamp Body Material PC
IP Rating IP65
Certification CCC, CE, C-tick, Energy Star, EMC, ETL, GS, LVD, SAA, UL
Place of Origin Zhejiang, China
Brand Name YUANHUI
Model Number Other, LMF

Specifications

led vaporproof lights for Production workshop
AC:100-240V, 277V 50/60Hz
95lm/w Ra>80 5yrs Warranty
UL, DLC, GS,CE, EMC,





Model: LMF-34W



 led vaporproof lights for Production workshop



   1.Model Name:LED triproof lamp



   2.Model No:LMF-34W





   1.Housing Material:PC



   2.Diffuser Material:PC



   3.Product Size (mm):1560 *120*108



 34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop







1.Input Voltage:AC100-240V,277V

2.Input Frequency:50/60Hz

3.Power Factor:≥0.95

4.Input Power:34W

5.Lamp Efficiency:90%

6.LED:5630

7.LED Quantity:78PCS

8.LED Lumen:Clear Diffuser:3400LM / Opal Diffuser:3300LM

9.Color Temperature: Warm White:2700-3000K   Cool White:4000-4500K   Daylight:6000-6500K

10.Ra:Ra>80

11.Working Temperature:Working Environment: -35°C-45°C

12.IP Rated:IP65

13.Lifetime:>50000h





1).Luminous Intensity Distribution Diagram:



34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop



 2).AAI Figure:

 34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop



3).Illumination data:



Lamp height Central Lumen (Lux) (Opal diffuser) Average Lux (Opal diffuser) Area (cm)
1m 1880 644 260
2m 470 161 512
3m 209 72 782
4m 117 40 1043
5m 75 26 1300







NW

 3.6KG
PE bag 1630*170mm
Manual instruction A4 Paper
Styrofoam A 130*100*37.5
Styrofoam B 130*100*77
Inner box 1600*138*108
Outside Carton 1620*290*230





34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop





LED triproof lamp is an efficeint outdoor lamp,with high output lumen. It is widely used in Car Parking Lot, Warehouse, Train station and other Publich areas.



Advantages:



1).The first advantage of this lamp is its heat dissipation system, which increase lamp’s lifetime largely. In detail, it uses heat sink and MCPCB to dissipate the heat caused by LED chips and using Air convection to cool the working environment of driver.



2).Using Air convection theory: The driver of this lamp is isolated in a separate room, we call it ventilated driver room, with a small board coving the top. On the board, there are many small holes, and in the bottom of the room, has four small holes.



Ventilated driver room: warm air goes out through driver cover holes and cool air supplies from bottom holes.



34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop







3).Moreover, this lamp has function of sensor, emergency kit and DALI system.





If customers want the lamp light on automatically when people pass and turn off or only keep 20% light when people leaves, it could put sensor into the lamp. Or if other customers want the lamp still light on for 2 to 3 hours when the power cut, it could put



emergency kit inside the lamp. Even, we could apply DALI system with this lamp, using computer to control all lamps in one area, it is really easy and efficient, saving lots of work for people.





4).The bright spot of the lamp is the fast connect system, by using male and female connectors, it could save 70% time to install lamps and save lots of labor cost nnect wires to the removable male connector, and push it into the lamp, connect with female connector.



 34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop



5). It has all certifacates that authorized by DEKRA test lab, including CE-LVD, EMC, ROHS, GS, SAA, C-TICK, UL, CUL, DLC.



34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop



34W 1560mm 2ft CE ROHS led vaporproof lights for Production workshop



Clear   Lens     Total Power        lumen                   Ra Product Size(mm)
LMF12-600 12W 970     Ra >80 600*120*108
LMF24-600 24W 2290 Ra >80 600*120*108
LMF24-1160 24W 2360 Ra >80 1160*120*108
LMF36-1160 36W  3540   Ra >80  1160*120*108
LMF48-1160 48W 4540 Ra >80 1160*120*108
LMF34-1560 34W 3030 Ra >80 1560*120*108
LMF54-1560 54W 5150 Ra >80 1560*120*108
LMF70-1560 70W 5600 Ra >80 1560*120*108
WP-76W 76W 5700lm Ra >80 1860*110*86
