Round IP66 LED Bulkhead

Round IP66 LED Bulkhead photo-1
US$ 15 - 20 MOQ: 100 Sets
Key Specifications
Get Latest Price
LED Light Source:
LED, SMD3528 EPISTAR
Install Style:
Surface Mounted
Input Voltage(V):
100-240
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source LED, SMD3528 EPISTAR
Install Style Surface Mounted
Input Voltage(V) 100-240
Lamp Power(W) 14
Lamp Luminous Flux(lm) 1100
Lamp Luminous Efficiency(lm/w) 78
Color Temperature(CCT) Cool White
Working Temperature(℃) -25, 50
Working Lifetime(Hour) 50000
Lamp Body Material PC
IP Rating IP65
Certification BV, CCC, CE, GS, LVD, UL
Place of Origin Zhejiang, China
Brand Name YH
Model Number RBH-14W

Specifications

LED bulkhead light
AC 110-240v 50/60Hz
IP65 protection level
Can be with sensor, Emergency kit

IP65 LED BULKHEAD





Features of LED BULKHEAD



  • UV stabilized compact resistant pc enclosure
  • Opal or transparent cover
  • 7 to 8 high lumens epistar SMD 3528 chip
  • Class: II,    IP66
  • Impact resistance : IK08
  • Glow Wire Test: 850 degree





Specification of LED BULKHEAD



  • It can be fitted with sensor and Emergency kit
  • LED/Qty: SMD 3528 (EPISTAR)   196PCS
  • Total Power: 14w
  • Diffuser type: Opal diffuser
  • Lumen: 1100lm
  • Color temperature: 3000k-6500k



Size of LED BULKHEAD





Model No. Product Size (D*H)mm Qty/Carton Carton Size LF (mm)
RBH-14W 300*90 8 620*380*310 108

Round IP66 LED BulkheadRound IP66 LED Bulkhead







Fotos of LED BULKHEAD





Round IP66 LED Bulkhead









Business Conditions



  • MOQ: 100PCS
  • Delivery time: 20days
  • Warranty: 50000hrs
  • Payment: 30% deposite and 70% based on the B/L
  • Transportation: By sea or by air (DHL/TNT/UPS)
  • Delivery time for samples: 10days
