Security Reliable 12v Led Driver Power Supply 2a,power ac Adapter
US$ 12.1 - 13
MOQ: 24 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
XINWEIDA
Model Number:
HX-350KC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality 5V,12V Dreambox Power Adapter for dc Home AppliancesUS$ 2.4 - 2.5MOQ: 24 Pieces -
Good Use Ygy 122000 Hot Sale Factory Price ac AdapterUS$ 3.2 - 3.4MOQ: 24 Pieces
-
Top Selling dc Adapters 29v Power Pack for Recliner Sofa Power SupplyUS$ 1.5 - 1.7MOQ: 24 Pieces
-
High Quality ac Power Adapter 12v 15a Power AdapterUS$ 1.1 - 1.3MOQ: 24 Pieces
-
High Quality Hot Selling Zf120a-1203000 ac dc Power AdapterUS$ 1.1 - 1.3MOQ: 24 Pieces
Place of Origin
Hunan, China
Brand Name
XINWEIDA
Model Number
HX-350KC
Output Power
Other, 350W
Output Type
Single
Input Voltage
Other, 180~264V
Output Voltage
12V
Output Frequency
50/60Hz
Output Current
29.2A
Security reliable 12v led driver power supply 2a,power ac adapter
Security reliable 12v led driver power supply 2a,power ac adapter
Product Advantages
- Dual transistor forward circuit plan, more stable, more reliable
- Built-in EMI filter circuit, no interference, no blink or slash phenomenon
- Short circuit, over load & over current protection, safe and secure
- Unique copper slice built-in transformer technology, low temperature & good EMC performance
- The output inductance using alsifer sendust material (Fe-Si-Al Alloy Core), high output efficiency
- Sufficient power output, 100% full load burning tes
You may like this :
|
|
|
|
|
|
Specification |
Size(mm) | Working Temperature | Efficiency(>) | AC Input Voltage Range | AC Inrush Current | Output | Power | Protection | Protection Mode |
| HX-25-12 | 85*58*37 | -20~40C | >82% | 100~240V | 100Amp max | 12V/2.1A | 25W | OLP,SCP |
Hiccup Mode |
| HX-60-12 | 159*98*42 | -20~40C | >82% | 100~240V | 100Amp max | 12V/5A | 60W | OLP,SCP | Hiccup Mode |
| HX-100-12 | 159*98*42 | -20~40C | >82% | 100~240V | 100Amp max | 12V/8.33A | 100W | OLP,SCP | Hiccup Mode |
| HX-120-12 | 199*98*42 | -20~40C | >82% | 180~240V | 100Amp max | 12V/10A | 120W | OLP,SCP | Hiccup Mode |
| HX-150-12 | 199*98*50 |
-20~40C | >82% | 180~240V | 100Amp max | 12V/12.5A | 150W | OLP,SCP | Hiccup Mode |
| HX-200A-12 | 199*110*50 | -20~40C | >82% | 200~240V | 100Amp max | 12V/16.67A | 200W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| HX-250A-12 | 199*110*50 | -20~40C | >82% | 200~240V | 100Amp max | 12V/20.8 | 250W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| HX-400C-12 | 261*103.5*65 | -20~40C | >82% | 180~240V | 100Amp max | 12V/33.3A | 400W | OLP,SCP | Hiccup Mode |
|
241*124*65 | -20~40C | >82% | 180~240V | 100Amp max | 12V/41.7A | 500W | OLP,SCP | Hiccup Mode |
| HX-75KC | 159*98*42 | -20~40C | >82% | 180~264V | 100Amp max | 12V/6.25A | 75W | OLP,SCP | Hiccup Mode |
| HX-350KC | 215*115*50 | -20~40C | >82% | 180~264V | 100Amp max | 12V/29.2A | 350W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| HX-150KC | 199*98*50 | -20~40C | >82% | 180~265V | 100Amp max | 12V/12.5A | 150W | OLP,SCP | Hiccup & deadlock Mode |
| HX-200KC | 199*110*50 | -20~40C | >82% | 180~264V | 100Amp max | 12V/16.67A | 200W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| HX-250KC | 199*110*50 | -20~40C | >82% | 180~264V | 100Amp max | 12V/20.8A | 250W | OLP,SCP | Hiccup & deadlock Mode |
| HX-400KC | 214.5*114*50 | -20~40C | >82% | 180~264V | 100Amp max | 12V/33.33A | 400W | OLP,SCP,OVP | Hiccup & deadlock Mode |
| KR-15-12 | 115*49*25.5 | -20~40C | >82% | 100~240V | 100Amp max | 12V/1.25A | 15W | OLP,SCP | Hiccup Mode |
|
199*99*50 | -20~40C | >82% | 180~240V | 100Amp max | 12V/29.2A | 350W | OLP,SCP,OVP | Hiccup & deadlock Mode |
|
Feature | Short circuit,overload,over-current protection | |
| Model Link | Indoor 5V Series | HX-200-5 HX-200E-5 HX-200F-5 HX-300-5 HX-400-5 | |
| Indoor 12V Series | HX-75-12KC HX-350KC HX-150-12KC HX-200-12KC HX-250-12KC HX-400-12KC HX-25-12 HX-60-12 HX-100-12 HX-120-12 HX-150-12 HX-200A-12 HX-250A-12 HX-400C-12 HX-500-12 KR-15-12 KR-350-12 | ||
| Indoor 24V Series | HX-60-24 HX-100-24 HX-400C-24 HX-500-24 KR-25-24 |
||
| Outdoor Series | HXS-30-12 HXS-60-12 HXS-100-12 KRF-200 KRF-350-5 KRF-150-12 KRF-400-12 |
||
| AC AD Adapter Series | HX08-1201(219) HX08-1201(319) HX08-1202(218H) HX08-1202(2000) HX08-1203(301) HX08-1205(608) HX08-1206-(608) | ||
