Fire Alarm Heat Detector

US$ 3 - 7 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

P&H

Model Number:

H64-2

Shenzhen P&H Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name P&H

Model Number H64-2

Specifications

heat detector for fire
low power consumption
2 wire 24V, Fixed and Rate of rise Temperature
OEM available
Delivery on time

Product Description

Product description

Name

Heat detector

Fire alarm heat detector

Features

1.Moden Stylish design

2.Low Power consumption 1.Moden Stylish design

3.Remoted LED indicator output(2 wire)

4.Non-polar input power supply

5.Extended warranty

6.Easy Installation and maintenance

Characteristic

Dual LEDs for 360-degree visibility

Twist-off mounting for fast installation

Technical Data

Model	H64-2	H64-4
Operating Voltage	DC9~35V
Standby Current	55uA	12mA(NC), 500uA(NO)
Alarm Current	35mA@DC12V, 83mA@DC24V	3mA(NC), 19mA(NO)
Alarm Output	Conventional alarm output & LED flash	Relay output and LED flash
Smoke Alarm Density	2.06%/ft
Installation Method	Ceiling Mounted
Operating Temperature	-10°C ~ +55°C
Operating Humidity	95%RH(max)
Dimensions	100mm(Dia)x48mm(H)

Ordering Information

Model	Detail
H64-2-FH	2 wire Fixed Temperature(57 °C ,135F)heat detector
H64-2-RH	2 wire Rate of Rise (8-15 °C /min)heat detector
H64-2-FRH	2 wire Fixed Temperature (57 °C ,135F) & Rate of Rise (8-15 °C /min)heat detector
H64-4-FH	4 wire Fixed Temperature(57 °C ,135F)heat detector
H64-4-RH	4 wire Rate of Rise (8-15 °C /min)heat detector
H64-4-FRH	4 wire Fixed Temperature (57 °C ,135F) & Rate of Rise (8-15 °C /min)heat detector
