Relay Output and LED Flash Combined Heat and Smoke Detector

Shenzhen P&H Electronic Co., Ltd.
Relay Output and LED Flash Combined Heat and Smoke Detector thumbnail-1
Relay Output and LED Flash Combined Heat and Smoke Detector thumbnail-2
Relay Output and LED Flash Combined Heat and Smoke Detector thumbnail-3
Relay Output and LED Flash Combined Heat and Smoke Detector thumbnail-4
Relay Output and LED Flash Combined Heat and Smoke Detector thumbnail-5
Relay Output and LED Flash Combined Heat and Smoke Detector thumbnail-6
Relay Output and LED Flash Combined Heat and Smoke Detector photo-1
Relay Output and LED Flash Combined Heat and Smoke Detector photo-2
Relay Output and LED Flash Combined Heat and Smoke Detector photo-3
Relay Output and LED Flash Combined Heat and Smoke Detector photo-4
Relay Output and LED Flash Combined Heat and Smoke Detector photo-5
Relay Output and LED Flash Combined Heat and Smoke Detector photo-6
US$ 3 - 7 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
P&H
Model Number:
HS53P-4
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name P&H
Model Number HS53P-4
relay output and LED flash combined heat and smoke detector
Product Description
relay output and LED flash combined heat and smoke detector

Name

Relay output and LED flash heat&smoke detector
HS53P-2  2-wire Smoke & Heat Detector
HS53P-4  4-wire Smoke & Heat Detector

Features

Designed to comply with EN54 standards

2 wire or 4 wire optional

Fixed temperature 57ºC,135F heat sensor

Non-polar power input

Extended warranty

Easy Installation and maintenance

Characteristic

Dual LEDs for 360-degree visibility

Twist-off mounting for fast installation





Technical Data:

Model

HS53P-2

HS53P-4

Operating Voltage

DC 9-24V



Standby Current

300uA

12mA(NC), 2mA(NO)

Smoke Alarm Density

2.06%/ft

Alarm Output

Conventinal alarm output and LED flash

Relay output (NO/NC) and LED flash

Installation Method

Ceiling Mounted

Operating Temperature

-10°C ~ +55°C

Operating Humidity

 95%RH(max)

Dimensions

100mm(Dia)*48mm(H)



Pack Ship & Payment
