Help CenterLan Tester
Related Products
Specifications
POWER SUPPLY: DC 9V reduplicated battery
ELECTRICITY-CONSUMING: 20MA
BULK: 10.5*10.5*2.6 mm
WEIGHT: 200G
Multifunctional Network Cable Tester
Technical Guideline:
TEST CABLE:RJ45,UTPSTPFTP?/font>
POWER SUPPLY:DC 9V reduplicated battery
ELECTRICITY-CONSUMING:20MA
BULK:10.5*10.5*2.6 mm
WEIGHT:200G
Test by cables of the Same BNC Axes:
1.Put one end of the cable into both main tester and BNC socket,and put the other into the remote tester.
2.Switch on the power,which works if the light is on.
3.BNC light will not be on when the cable os connected.Any flash of the light means an improper cable is connected.
4.Press the button on the left of the main tester.If the light is green,the cable works;if not(means red or any other color
of light),the cable is out of work.
Test by Twin-twisted Cables:
1.Put one end of the cabke into the main tester.
2.Switch on the power,which works if the light flashed.
3.Once switched on,LEDS of the remote tester will scan the cable accordingly.If the cables are good,the corresponding
LEDS will turn green sequently.If the cables are out of work,the LEDS will first turn green then red or others,or the LEDS
will not be on or be on disorderly.
4.If the cables are shielded,shielding is tested when GND is turned on.If shielding is normal,the corresponding LEDS
and GND will turn green.IF not,the LEDS will first become green then red or will not be on at all.
Notice:
1Please confirm a 9V alkalescent battery has been placed in the box.
2.If you don't test the shield doubl,please keep the GND switch closing.
