Y-type Stainless Steel Angle-Seat Valve 's Summary:
Full Stainless Steel Angle Seat Valve are widely used in chemical process, food processing(no sanitary), sterilizers, autocalves, highly viscous liquid etc equipments.Stainless Steel Angle-Seat Valve's Specifications:
| Control type | Normal closed,normal open,double acting |
| Cylinder material | stainless steel, polyamide PA |
| Pneumatic accessories | Limit switch, locator, solenoid valve, filter relief-pressure valve, manual operating device |
| Medium temperature | PTFE:-30~180℃ F46:-30~+220℃ |
| Environment temperature | -30~80℃ |
| Nominal pressure | 1.0~1.6MPa |
| Nominal diameter | DN10-50-80mm |
| Connection type | Thread,Flanged, Clamp, Welded |
| Body construction | One-piece, Y-type |
| Body material | 304,316, 316L |
| Spool pressure | 304,316, 316L |
| Seal material | PTFE,F46 |
| Applicable medium | Steam, water, air, oil etc. |
Angle seat valves's installation and disassembly :
1. Based on concrete conditions select the valve installations direction
2. Installation charge of road should be cleaned to ensure no impurites or medium welding slag, so as not to damage the valves, causing leakage.
3. Install welded vavle, be sure to detach the valve actuator
4. Select the appropriate adjustment range of the regulator
5. Ensure that the air pressure range sufficient capacity
6. Check to ensure seal integrity of the connection
7. Valve repair or replacement, the demolition of the body and the connecton in the room temperature, the valve under the state open to avoid damage to the thread
8. Installation and connection in the body the threads coated with a small amount of thread grease, and tighten
We also supply the plastic angle seat valves, bronze angle seat valves, more information, welcome to contact with me, or visit our website:, thank you
We also supply the full stainless steel angle seat valves, more information, welcome to contact with me, or visit our website:, thank you
