Help CenterUS Standard Brushed Aluminum Desktop Socket With Rotating Power Plug/Tabletop Socket
Related Products
-
Electric Office Power Data Outlet Box/CE Approved HDMI Motorized Pop Up OutletUS$ 45 - 105MOQ: 10 Units -
Desktop Motorized Pop Up Box With VGA Cable/Tabletop Rotatable SocketsUS$ 45 - 105MOQ: 10 Units
-
CE Approved Desktop Flip Socket/Motorized Pop Up Power Plug With US OutletUS$ 50 - 105MOQ: 10 Units
-
Electric Desktop Socket Box With VGA&HDMI Cable/Meeting Table Power PlugUS$ 75 - 105MOQ: 50 Units
-
Motorized Pop Up Box With Audio Video Cable/Electric Desktop Power Socket With RJ45US$ 45 - 105MOQ: 10 Units
Specifications
electric desktop socketautomatic flip open and closed by power
aluminum alloy finishing panel
Fixable soclets
1.5m cables
US Standard Brushed Aluminum Desktop Socket with Rotating Power Plug/Tabletop Socket
Introduction:
EK series Electric Desktop socket is an innovative solution to provide electric, data and other AV interfaces on desktop office furniture. EK series Electric Desktop Socket is powered by an electric drive motor that rotate the sockets to the hidden position when unused. A photoelectric eye inside electric desktop socket will prevent rotation if there was an obstruction on the top of electric desktop socket during working.
Feature:
1, Electric Desktop socket offer outlets for accessibility to electric, internet, telephone, VGA, HDMI,3.5 Audio, USB, MIC and could be customized for other data and AV interfaces.
2, Electric Desktop socket rotate all sockets to the hidden position by press the touch button, to provide a clean and elegant surface of worktop. Also Electric Desktop socket prevent accidental spillage of fluids into the product.
3, A photoelectric self-lock device inside the Electric Desktops Socket prevent sockets from rotating if one of socket units is plugged. Also prevent cable damage and hand jammed during operation.
4, Electric Desktop Socket contain an electric drive motor, ensure reliable rotation and the ability to orient itself to the proper position.
Characteristic
1, high quality aluminum alloy finishing with motors
2, A=A strong carton with foam cushion and waterproof film
3, white/black/gold color is available for color selection
4, Power plug and voltage could be changed accordingly.
5, OEM with logo on product and packing is available
6, Customized made is available
Application:
Electric Desktop Socket widely use in furniture, like conference table, desk, workstation, and hotel room, healthcare setting, along with raining and educational application.
Parameter:
| Model No. | EK9211B |
| Material | aluminum alloy |
| Color | silver or black |
| Length of Cables | 1.5 meter |
| Connector with Cables |
2-US power, 2-Network, 1-USB, 1-HDMI, 1-3.5 Audio With Power cable, network cable, USB cable, HDMI cable,3.5 Audio cable |
Selection Parts for OEM
|
Power Socket (Selectable ) |
Universal |
100-240V AC,50/60HZ,5A |
US version |
100-240V AC,50/60HZ,5A |
|
UK version |
100-240V AC,50/60HZ,5A |
|
Central EU version |
100-240V AC,50/60HZ,5A |
|
FR and BL version |
100-240V AC,50/60HZ,5A |
|
South Africa version |
100-240V AC,50/60HZ,5A |
|
Australia version |
100-240V AC,50/60HZ,5A |
|
|
Cable (Selectable) |
HDMI cable |
|
VGA cable | ||
USB cable | ||
RJ45 cable | ||
Microphone cable | ||
Lan/ Network cable | ||
Video/RCA cable | ||
3.5 audio cable | ||
Working temperature |
5°C ~ 45°C |
|
Working humidity |
10% ~90 % |
|
Storage temperature |
- 20 °C ~70 °C |
|
Storage humidity |
5% ~95 % |
|
Professional Service:
1, Any of inquiries will be response within 48 hours
2, Sizable accessories of products for replacement
3, Sample of Electric Desktop Socket is available.
Warranty:
Study the user’s manual carefully before installation.
All of our products provide 12 months warranty! The warranty period starts from the goods receipt by initial consignee.
Payment:
T/T, L/C, Western Union, Money Gram, Crash is acceptable
Operation Method:
1, the indicator light is illuminated when product power up.
2, Press the red touch button if unused, the product will rotate 180 degrees to the hidden position. Press the green touch button if use, the product will rotate 180 degree to the desktop.
Pictures:
Production Line:
Product Packing Detail:
CE Certification:
