DXDT8 Factory Price Tea Bag Packing Machine

DXDT8 Factory Price Tea Bag Packing Machine thumbnail-1
DXDT8 Factory Price Tea Bag Packing Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Automatic Grade:
Automatic
Driven Type:
Pneumatic
Place of Origin:
Anhui, China
Contact Supplier Request Quote Chat Now
Anhui Zengran Packaging Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Automatic Grade Automatic
Driven Type Pneumatic
Place of Origin Anhui, China
Dimension(L*W*H) CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Engineers available to service machinery overseas
2.Customized machine is available
3.CE ISO



Company Information -- Tea Bag Packing Machine



1- Anhui Zengran Machinery Automation Co.,Ltd is a high and new technology enterprise

    which specialized in R&D and manufacture automatic packaging machine since 1995.

2- Specialized in 1kg-50kg powder & granule automatic bag packaging machine, secondary

    packaging machine (small bags into big bag), bags/battles into box line Robot Palletizer,

    automatic packing and packaging line, bag-sewing machine.



                                      WELCOME TO VISIT OUR COMPANY !!!





Application -- Tea Bag Packaging Machine



This automatic tea bag packing machine has functions of filling, heat sealing, threading, labeling and over wrapping.

/watch?v=T6zNYHKUKxQ









Specifications -- Tea Bag Packing Machine



Working Speed:

up to 90-100 bags/min

Dosing Range:

Max. 8 cc (cubic centimeter)

Filter Bag (Inner Bag):

Shape: 4 side sealed rectangular single chamber filter bags
Size: 60 mm x 50 mm ( 2.36 in x 1.97 in)
Filer Paper: heat sealing type, 16.5g/m2(21g/m2, 23g/m2) in web(roll) of 120 mm ( 4.72 in ) width, out dia. 400 mm ( 15.75 in ) inner dia. 75 mm ( 2.95 in )

Tag:

Shape: square, rectangular and octagonal
Size: 28 mm x 24 mm (1.10 in x 0.94 in)
Tag paper: 70g/m2 printed on both sides and notched in Rolls of 28 mm (1.10 in) width.

Envelope (Out Bag):

Shape: as envelope
Size: 70 mm x 65 mm ( 2.76 in x 2.56 in)
Envelope Paper: heat sealing type, 70 g/m2, in Rolls of 65 mm ( 2.56 in ) width.

Cotton thread:

Cotton

Glue For Tag:

Poly Vinyl Acetate

Power:

2.5 kw

Voltage:

380v/50hz, 3 phrase or per customer's request

Machine Size:

H 1700 mm W 900 mm H 2190 mm
(H 66.93 in W 35.43 in H 86.22 in)

Shipping Size:

 L 1300 mm W 1100 mm H 2000 mm

(L 51.18 in W 43.31 in H 78.74 in)

Machine Weight:

600kgs





Advantages -- Tea Bag Packaging Machine





  • Heat sealed rectangular single chamber filter bags with thread, tag & envelopes
  • Special feeder for tea leaf.
  • Auto counting envelopes at exit channel for manual removal
  • In GMP standard
  • Square, rectangular and octagonal tag can attached
  • Only naked filter bags is available
  • Hygienic, airtight, waterproof envelope guaranteeing the preservation of tea











Packaging & Shipping -- Tea bag Packaging Machine

DXDT8 factory price tea bag packing machine



Packing Machine

Our Promise--Tea bag packing machine

Custom-made machine:

We have Great customized and design ability. Any required custom made machine can be

designed and manufactured for convenient operation and reasonable cost, making your

packaging system work smoothly.

Installation:

1- We provide videos and instruction manual to show the process of installation.

 2- We provide training for installation for free in our factory.

3- We can send technician to buyer's factory to install the machine and provide training service.

After Sales Service:

1- One year quality warranty and free lifetime technique support.

2- Free spare parts would be supplied if machine broken within warranty period.

3- After the warranty period, the spare parts for replacement are offered based on certain charge.



Contact Information--Tea bag packing machine

Thank you for your inquiry and we will provide packaging solutions according to

your requirements immediately.
