GFP3D1 Autaomatic Bag in Bag Packaging Machinery

GFP3D1 Autaomatic Bag in Bag Packaging Machinery thumbnail-1
GFP3D1 Autaomatic Bag in Bag Packaging Machinery photo-1
US$ 40,000 - 70,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food
Packaging Type:
Other, bags
Contact Supplier Request Quote Chat Now
Anhui Zengran Packaging Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food
Packaging Type Other, bags
Packaging Material Other, wooden case
Automatic Grade Automatic
Driven Type Electric
Power 6KW
Brand Name zengran
Model Number GFP3D1

This automatic bag in bag packing machine is  majorly accomplish the full-auto packaging  procedure that putting packed sachets as required orderliness into woven bag ,which realizes automated job from raw material to packed woven bag .It from all aspects to save more cost of production for customers ,such as economize the cost of human sources,and higher the effciency,it is widely used on washing powder,salt,seed,milk powder etc.powder or granule packaging ,is major company's first choice machine.

The unit consists of horizontal conveyor,double-deck slope conveyor,high speed conveyor,counting bagarrange machine,woven bag automatic packaging machine,sewing machine,end product conveyor.
Process Flows:Raw material--automatic vertical weighing packing machine--sachet products--horizontal conveyor-- double-deck slope conveyor-- high speed conveyor-- counting bagarrange machine-- woven bag automatic packaging machine--sewing machine-- end product output.
Advantages:
1.Fully automatic plasticsachets packaging can realize the complete automation of material  lifting,counting,sachet-making,feeding,printing,sealing,end sachets conveying.
2.Automatic woven bag packaging machine can realize auto bag fetching,bag-open,counting,feeding,shift output,leading auto sewing machine . Realize unmanned packaging process.
 3. This unit adopts touch screen control ,man-machine comes better,more convenient to operation change size and repair,safety and reliability.
4.Can realize various spread pattern to content requirements from different customers.

Technical parameters:
Packaging capacity:150g-3000g
GFDS/3 model:packed sachets vertical line stack up into woven bag, Max. speed  80 sachets/min.
GFXP/1 model:packed sachets levelly stack up into woven bag.  Max. speed  80 sachets/min.
GFXP2/1 model:packed sachets levelly stack up into woven bag.   Max 160 sachets/min.
2.Packaging material:rigid plastic woven bag,bag size according to product size.
3.Packaging speed:woven bag 6-10 bags/min.,sachets:60-180 sachets/min.
4.Spread pattern include single-row,biserial,vertical line etc.
5.Compressed air:0.6-0.8MPa,air flow:0.8 m3/min
6.Power: 6Kw ,380V ,50Hz
