Pop Up Desktop Power Plugs/ Hydraulic Pop Up Socket Box/ Multi functional socket box
Introduction:
BP series desktop socket is designed as a table top socket box with multi-functional modules. Pop Up Connector is built in a pneumatic pressure spring pole, which can pop up the sockets with 45 degree. Desktop Power Plug works with the aluminum alloy connection plate. User can select the right plate with different modules accordingly to different application. All the modular plates of desktop hydraulic pop up box are direct connection.
Desktop Pop Up Outlet can be installed into high tier office, the luxury conference room, control room, hotel and multimedia classroom.
Feature:
hydraulic pop up box by pneumatic pressure gas pole quietly
Table top of pop up socket box is mountable
The aluminum alloy plate of office tabletop power outlets is 5mm
All the socket connectors and sockets of tabletop outlets are direct connection
Different sockets into tabletop media HUB box could be added as required
Various versions of power socket
Selling Points:
Easy access to connectors
Durable Pneumatic movement and mechanical latching mechanism
Black or silver brushed aluminum
Compact size with square bezel
Un-switch AC power 100~240V, 50/60HZ, 10A outlet
Characteristic
1, high quality aluminum alloy finishing panel
2, A=A strong carton with foam cushion and waterproof film
3, silver/black is available for color selection
4, Power plug and voltage could be changed accordingly.
5, OEM with logo on product and packing is available
6, Customized made is available
Application:
Desktop hydraulic pop up box is widely used on office furniture, high tier office, luxury conference table, hotel and multimedia classroom and training room.
Parameter:
| Model | BP605 |
| Material | aluminum alloy |
| Color | silver or black |
| Panel Size | 175*130mm |
| Box Size | 150*120*135mm |
| Detail Connectors | 1-power, 2-Network,1-Audio, 1-Video,1-VGA, |
Selection Parts:
|
Power Socket (Selectable ) |
Universal |
100-240V AC,50/60HZ,5A |
US version |
100-240V AC,50/60HZ,5A |
|
UK version |
100-240V AC,50/60HZ,5A |
|
Central EU version |
100-240V AC,50/60HZ,5A |
|
FR and BL version |
100-240V AC,50/60HZ,5A |
|
South Africa version |
100-240V AC,50/60HZ,5A |
|
Australia version |
100-240V AC,50/60HZ,5A |
|
|
Connector (Selectable) |
Computer |
15 pin HD VGA female |
Audio |
3.5mm stereo female jack |
|
Video |
RCA female |
|
Lan |
RJ45 ( CAT5e/ CAT6) network/data |
|
Telephone |
RJ11 voice |
|
USB |
USB2.0/3.0 female |
|
HDMI |
HDMI 1.3 female |
|
Microphone |
6.5mm stereo female jack |
|
XLR |
female jack |
|
DVI |
Female jack |
|
Switch |
press switch |
|
Working temperature |
5°C ~ 45°C |
|
Working humidity |
10% ~90 % |
|
Storage temperature |
- 20 °C ~70 °C |
|
Storage humidity |
5% ~95 % |
|
Professional Service:
1, Any of inquiries will be response within 48 hours
2, Sizable accessories of products for replacement
3, Sample of hydraulic pop up desktop socket is available.
Warranty:
Study the user’s manual carefully before installation.
All of our products provide 12 months warranty! The warranty period starts from the goods receipt by initial consignee.
Payment:
T/T, L/C, Western Union, Money Gram, Crash is acceptable
Pictures:
Company Production Line information
Boente had a full production line for different models of desktop socket.
