Specifications
It is widely used for industry palletizing,which can save a lot of labors .The machine is flexible to pallet in different ways.IRB 460 multi-purpose robot made by ABB is adopted.
Technical Parameters:
Load capacity: max.110Kg
Outreach distance: 2.4m
Repeat positioning accuracy: 0.2m
Repeat travel accuracy: 0.11m
Electricity required: 200 – 600V, 50 -60Hz
Power: 3.67KW
Travel times:
With 60kg load: 2190times/hour
With 110Kg load: 2040times/hour.
Manipulator
Comprises gripping cylinders, pneumatic motivation components, bag pressing cylinder, electromagnetic valves, and gripping hands made out of stainless steel.
Automatic Pallet Distribution System
Comprises pallet storage lot made of carbon steel, pallet lift mechanism, pallet conveyor,
fitted with photoelectric switches, suitable gear box, frequency converter and motors.
Technical Parameters
Pallet Size: 900-1200mm X 900-1200mm
Pallet distribution speed: min. 10pc/hour
Motor: 1.5KW
