Help CenterStainless Steel Frame Hepa Filter
Related Products
HEPA stands for high-efficiency particulate air. HEPA filter is a type of mechanical air filter; it works to collect the dust and offer the fresh air.
Size
Customized design is available for this kind of HEPA filter.
Applicatons:
The HEPA filters are widely used for terminal filtration in environments and industries which reques extremely high level of cleanliness, like: electronics, semiconductor man ufacturing, precision machinery, pharmaceuticals, hopstials, food processing,etc.
Material and operation condition
Media |
glass fiber |
Sealant |
Pu two-component polyurethane rubber |
Frame |
Aluminum/Galvanized/Stainless stee/Plastic |
Separator |
EVA hot melt bead |
Gasket |
EVA |
Efficiency |
99.99%~99.9995% at 0.3μm |
Max.Temperature |
70℃ |
Max.Humidity |
100% |
Optional aluminum thickness |
45~150mm |
HEPA air filter efficiency range
EN1822 |
Efficiency |
F5 |
45%@0.4μm |
F6 |
65%@0.4μm |
F7 |
85%@0.4μm |
F8 |
90%@0.4μm |
F9 |
95%@0.4μm |
| H10 | 85%@0.3μm |
| H11 | 95%@0.3μm |
H12 |
99.5%@0.3μm |
| H13 | 99.99%@0.3μm |
| H14 | 99.995%@0.3μm |
Mini Pleated HEPA Filter Technology parameters
| model |
width (mm) |
height (mm) |
depth (mm) |
air flow (m³/h) |
initial resistance (≤pa) |
final resistance (pa) |
media area (m²) |
dust holding (g) |
efficiency |
| CRAC-610-HP001 | 305 | 305 | 50 | 200 | 200 | 400-600 | 1.8 | 100 | H13~H14 |
| CRAC-610-HP002 | 484 | 484 | 50 | 500 | 200 | 400-600 | 4.6 | 300 | H13~H14 |
| CRAC-610-HP003 | 610 | 610 | 50 | 800 | 200 | 400-600 | 7.5 | 450 | H13~H14 |
| CRAC-610-HP004 | 915 | 610 | 50 | 1200 | 200 | 400-600 | 11.2 | 700 | H13~H14 |
| CRAC-610-HP005 | 1220 | 610 | 50 | 1600 | 200 | 400-600 | 14.9 | 900 | H13~H14 |
| CRAC-610-HP006 | 305 | 305 | 69 | 260 | 200 | 400-600 | 2.5 | 150 | H13~H14 |
| CRAC-610-HP007 | 484 | 484 | 69 | 700 | 200 | 400-600 | 6.6 | 400 | H13~H14 |
| CRAC-610-HP008 | 610 | 610 | 69 | 1000 | 200 | 400-600 | 10.7 | 650 | H13~H14 |
| CRAC-610-HP009 | 915 | 610 | 69 | 1600 | 200 | 400-600 | 16.0 | 950 | H13~H14 |
| CRAC-610-HP010 | 1220 | 610 | 69 | 2100 | 200 | 400-600 | 21.3 | 1000 | H13~H14 |
| CRAC-610-HP011 | 610 | 610 | 90 | 1500 | 200 | 400-600 | 14.9 | 900 | H13~H14 |
| CRAC-610-HP012 | 915 | 610 | 90 | 2000 | 200 | 400-600 | 22.3 | 1200 | H13~H14 |
| CRAC-610-HP013 | 1220 | 610 | 69 | 2800 | 200 | 400-600 | 29.8 | 1800 |
Inside with plastic and carton to protect the HEPA filter; outside is in plywood.
1.We manufacture all kind of the air filters, like ULPA filter, HEPA filter, pocket filter, pleat filter, V-bank filter, etc.
Kunshan CRAC Clean Technology Co., Ltd is a professional Manufacturing factory who main produce Air filter and clean room equipment found in 2006, located in the thriving industrial city of Kunshan,30Km away from Mega-City Shanghai.
Follow company development requirement, CRAC found a branch company(Kunshan FengRuiDa Air conditioning purification equipment Co.,ltd) in 2007, main specialize in Maintenance service for HVAC project .
The range of CRAC production including: HEPA Filter(Mini-pleated HEPA/Separator HEPA), Medium Filter(Medium Bag Filter/Medium Panel Filter), Pre-Filter, Activated Carbon Filter, etc.
1. How long can this HEPA filter to be used?
It's depending on the working environment. If the environment is not very dirty,usually it can be used for over 1 year.
2.Does your factory has any certifications?
Yes, we have past the ISO9001 & CE certifications. Meantime, all the HEPA filters must be test one by one before shpiment.
3.Does your factory manufacture the nonstandard size?
Yes, we can according your need to manufacture the sizes.
4.How can I contact the person to discuss the details?
Please send an inquiry for us, we will arrange the professional salesman to follow your need.
5. If I send an inquiry, how long does the person to reply?
If it's the working days, usually we will reply you wihin in 24 hours. If it's on the weekend or on the holiday, usually it will need 2~3 days.
6.For more questions, please contact us directly.
