Handheld long range HF RFID Reader with WI-FI GPRS Camera wifi pos terminal

Specifications

1. wifi pos terminal
2. 3 operating system PDA
3. 1GHz High speed CPU.
4.CE& RoHs Certificated





Selling Point>>>

• Android 4.0 Handheld industrial pda
• Superior scalability: support RFID reader+ barcoder reader+DGPS+ Thermal printer
• OEM, ODM are available
• Symbol/ Honeywell / New land Scan engine
• product quality assurance, it passed the CE& RoHs
• Support 3 OS:Android 4.0/ WinCE/ Windows mobile 6.x





Features:



 Support Android 4.0 OS, Windows mobile 6.1/6.5 OS, WinCE OS







Rugged IP65

MT35 can withstand multiple drops onto concrete from 1.5 meters.

IP65: Waterproof, dustproof and drop resistant. Suitable for all kinds of complicated industrial environment.







4500mAH large capacity battery

 Long time continuous working with standard 4500mAH.





Connect port

USB 2.0/RS232/USB Host/ Cradle/ SIM card/ TF card/ Power jack/ Audio Jack





 TT35 data sheet



OS option
OS	option 1	Windows mobile 6.1/6.5
	option 2	WM CE 6
	option 3	Android 4.0
Hardware
Core board
CPU		TI3715 A8 1Ghz
WWLAN	option 1	without modem
	option 2	Huawei MU609 Module: GSM band 850/900/1800/1900MHz, GPRS, EDGE                                 UMTS 850/900/1900/ 2100MHz HSPA )
Memory	Flash ROM	512MB
	RAM	512MB DDR
	Extend Slot	Micro SD 32G (SDHC)
Motherboard
Display		3.5inch TFT LCD (Transflective screen VGA )
touch screen		4-wire resistive
Form Factor		Bar type classical Pocket PC,Industrial appearance
GPS		UBLOX 6010
Bluetooth		JORJIN WG7310 Bluetooth
WiFi		JORJIN WG7310 WiFi (802.11 b/g/n)
Fingerprint reader(Optional)		SM-621B(Optical fingerprint)
Thermal Printer (Optional )		Direct thermal line printing
Far Infrared Meter Reading (Optional)		IEC62056-21(IEC1107) communication protocol
RFID Reader	option 1	LF RFID(134.2khz, ISO11784/11785, FDX-B/HDX)
	option 2	LF RFID(125KHz)
	option 3	HF RFID(13.56MHz ISO 14443A/B)
	option 4	HF RFID(13.56MHz ISO 1443A/B   ISO 15693)
	option 5	NFC Reader (only android OS)
	option 6	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct mode----with AS3992 shipset
	option 7	UHF RFID 860-960MHZ ISO18000-6C (EPC Gen2) / ISO18000-6A,B compatibility in direct modee----with inpinj R2000 shipset
barcode scanner	option 1	NEWLAND:EM1300(1D barcode reader)
	option 2	NEWLAND:EM3000(1D/2D barcode reader)
	option 3	symbol:SE955(1D laser barcode reader)
	option 4	HoneyWell:N4313 (1D laser barcode reader)
	option 5	Honeywell:5100(1D/2D barcode reader)
	option 6	Symbol: se4500(1D&2D barcode reader)
External Interface		USB HOST/RS232(Customized)
Protection class		IP65
Drop resistance level		1.5m
Camera Function	Camera	5MP Camera
	Video	Support still image and video capture
Keypad	Front	30keys
	Side	4keys
Interface	Mini-USB connector	USB2.0 connection
	SIM card slot	Yes
	PSAM card slot*2	option
	TF card slot	Yes
	power jack	Yes
	Audio Jack	Yes
Battery	Type	rechargeable Li-ion battery 4500mAh
	Standby Time	500hours
	Calls Time	Up to 6hours
	Charging Time	4 hours
Physical Characteristics	Dimension	182*82*36mm
	Weight	>400g with battery (according config)
