Shore Hardness Tester HT-6510F

FOB Price

US$ 150 - 200 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Landtek
Model Number	HT-6510F

Applications:

Model HT6510F is suitable for the hardness measurement of sponge.

* It meets standards of DIN 53505, ISO 868, ISO 7619, ASTMD 2240, JISK7215.

* With average calculate function.

* Peak value deposit function.

* Under-voltage alarm function.

* Use “USB data output” and “RS-232 data output” to connect with PC.

* Provide “Bluetooth ™ data output” choice.

Parameters Displayed	Hardness Result, Average Value, Max. Value
Measurement Range	0~100 HF
Measurement Deviation	<1 HF
Resolution	0.1 HF
Spring Force	455 gf
Sensor Head Diameter	25mm
Sensor Foot Diameter	80mm
Auto Switch Off
Battery Indicator	Low Battery Indicator
Operating Conditions	Temperature: 0 ~ 40 ℃ Humidity: 10 ~ 90 %RH
Power Supply	4 x 1.5 V AAA Size (UM-4) Battery
Dimensions	162 x 80 x 80 mm (6.4 x 3.1 x 3.1 inch)
Weight	490 g(Not Including Batteries)

Standard Accessories

1. Main Unit

2. Carrying Case

3. Operation Manual

Optional Accessories

1. Shore Hardness Tester Measurement Stand

2. Rubber Hardness Test Block (A / D Type )

3. USB, RS-232C data cable with software

4. Bluetooth data out put with software

Model Informations:

Model	Indenter	Tested Materials	Hardness Value
A	0.79 Truncated (Frustum) Cone	Soft Rubber, Elastomers, Natural Rubber Products, Neoprene, Resin, Polyester, Soft PVC,Lleather, etc.	20 ~ 90 A
B	R 0.1 Cone	Middle Hard Rubber Materials, Typewriter Rollers, etc.	Above 90 A, Below 20 D
C	0.79 Truncated (Frustum) Cone	Plastics and Middle Hard Rubber Materials	Above 90 B, Below 20 D
D	R 0.1 Cone	Fibre Plastics, Hard Rubber, Hard Plastic Materials, Plexiglas,Stiff Thermo Plastics, Formica, Print Roller, Vinyl-plate, Cellulose Acetate, etc.	Above 90 A
DO	R 1.2 Spherical Radius	Plastics and Middle Hard up to Hard Rubber Materials	Above 90 C, Below 20 D
O	R 1.2 Spherical Radius	Soft Elastic Materials, Print Rollers, Middle Firm Textile Fabrics, Nylon, Orlon, Perlon, Rayon	Below 20 DO
OO	R 1.2 Spherical Radius	Sponge- and Cellular Rubber, Foam Rubber, Silicone, Gel-like Materials	Below 20 O
E	R 2.5 Spherical Radius	Hard Sponge, EVA	Above 90 DO, Below 20 D
