Pallet wrapping machine with stretch film

FOB Price

USD $2,500 - $4,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao or Shanghai
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Application:	Apparel, Beverage, Chemical, Commodity, Medical, Textiles	Packaging Type:	Case
Packaging Material:	Wood	Automatic Grade:	Automatic	Driven Type:	Electric
Voltage:	220V,50HZ,1phase	Power:	1.5KW	Place of Origin:	Shandong, China
Brand Name:	Shunyi	Model Number:	T1650F	Dimension(LWH):	274516502863mm
Weight:	600kgs	Certification:	ISO9001,SGS,CE	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

T1650F Wraping Machine

1. Intelligent Human-computer interface; PLC easy operation control; Pre-stretch system 300% (customized).
2. Stable performance, working life 10 years, quality guarantee 2 years.
3. European standard design and manufacture, same quality, but Chinese market price; Pass CE certificate.
4. Accept customer’s design order, satisfy customer’s different requirements, and install weighting unit or automatic cutting film ect.
5. Widely used in glass products, hardware tool, electric product, paper, ceramic, chemical, food, beverage, building material and so on.
6. Improve logistic efficiency, reduce goods loss during transporting, has waterproof, dustproof, reduce product cost, improve packaging grade.

T1650F Automatic pre-stretch film wrapping machine
Wrapping product size	L(500-1200) mm × W(500-1200)mm
Wrapping height	L type:1800mm H type:2400mm Y type:2800mm
Packing efficiency	20-40 pallet/h
Rotary speed	0~15rpm rotary speed, adjustable, steady start and stop
Turntable size	Dia:1650mm Height:78mm
Turntable weight capacity	2000kgs
Up and down upright	Double chain structure, adjustable up and down speed by transducer
Control system	PLC programmable
Machine weight	700kg
Machine size	2745mm×1650mm × (2260-3260) mm
Power	Turntable 0.75kw, film carriage 0.4kw, upright 0.37kw

Detailed Images

Turntable

Film carriage

Touch screen

Certifications

Our Service

T1650E No pre-stretch film wrapping machine

Wrapping product size:L(500-1200)mm×(500-1200)mm

Wrapping height:L type:1800mm H type:2400mm Y type:2800mm

Packing efficiency:20-40 pallet/h

Turntable weight capacity:2000kgs

Machine weight:650kg

Power:Turntable 0.75kw, upright 0.37kw

T1650F-CS Automatic pre-stretch top platen film wrapping machine

Wrapping product size: L(500-1200) mm × W(500-1200)mm

Packing efficiency: 20-40 pallet/h

Work voltage pneumatic system:0.6~0.8Mpa 1000ml/min

Machine size: 2745mm×1650mm × (2260-3260) mm

Electric: Single phase AC220V/50Hz/1.5KW

Power :Turntable 0.75kw, film carriage 0.4kw, upright 0.37kw

T1800FZ-PL Pallet online film wrapping machine

Wrapping product size: (800-1200) mm × (800-1100)mm

Wrapping height: 1800~2800mm

Turntable weight capacity: 3000kgs

Machine weight: 1000kg

Machine size: 3000mm×2000mm × (2650-3650) mm

Power: Turntable 1.1kw,transporting 0.55kw, film carriage 0.37kw, upright 0.37kw AC380V /50HZ

Our Company

FAQ

You will care the following FAQ:

1. What about your stretch wrapping machine quality?
Our factory has 16 years experience in wrapping machine; already get ISO9001, SGS
certificate, CE certificate; already exported into many countries and areas; already got
customer’s good reputation.

2. What about your stretch wrapping machine price?
Quality is first, on the top quality basis, Sure you will get reasonable and satisfied price!

3. What about your company service for stretch wrapping machine?
Guarantee is one year, we will supply spare parts or send engineers to your side free,
we will give you service anytime, 24 hours, 7days.
