Borehole Geophysical Logging Survey System
Negotiable
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- chongqing
- T/T
You May Like
- Sand Water Filter/Water treatment plants
- Automatic Doypack Seal Machine (insert and sealing machine)
- Deep well level transmitter
- Portable gas analyzer for detecting and measuring gas concentration K850 for power station
- Liquid level transmitter
- IPX3/IPX4 Hand-held Water Spray Nozzle Test Device IEC 60529
Product Details
Place of Origin: | Chongqing, China | Brand Name: | Gold | Model Number: | Borehole Geophysical Logging Survey System |
Product Description
Borehole Geophysical Logging Survey System
- Coal Field Digital Integrated Logging
- Hydrological Engineering Digital Integrated Logging
- Solid Metal Ore Digital Integrated Logging
- Other Minerals Digital Integrated Logging
- External Laptop (Desktop PC)
- For upward logging, also for downward logging
- Receive digital signal, analog signal
- 8 taps of power supply current, Optional
- Automatic sampling as per depth interval, sampling interval arbitrarily
- Indoor simulation logging, repeatability observation of instruments and probes
- Membrane panel, attractive and durable
Technical Specifications
- 12bit A/D Conversion, Program-Controlled Magnification K=0.5~128
- Counting Channel: f≤500KHz
- Digital Signal Transmission Frequency: 9600bit/s
- Power Supply Cycle: 400ms
- Current: 2mA~500 mA Optional
- Signal Input Range: ≤±10V
- Continuous Working Time: ≤24 hr
- Power Consumption: <200W
- Volume: 420×260×210mm,
- Weight: <7Kg
- Working Temperature Range: -10°C~ +50°C
- Working Power Supply: AC220V±10% 50Hz ±5%
- Logging Speed: 0~30 m/min Adjustable (as per sampling interval)
