Geological Well Logging Equipment Manufacturer for Gamma, Resistivity, SP

  Geological Gamma, Resistivity, SP Well Logging Equipment Manufacturer

I. System Component:

Main instrument and software,

Winch and cable

Well logging probes

II. Features:

External Laptop (Desktop PC)

For upward logging, also for downward logging

Receive digital signal, analog signal

8 taps of power supply current, Optional

Automatic sampling as per depth interval, sampling interval arbitrarily

Indoor simulation logging, repeatability observation of instruments and probes

Membrane panel, attractive and durable.

III. Technical Specification:

12bit A/D Conversion, Program-Controlled Magnifcation K=0.5~128

Counting Channel: f ≤ 500kHz

Digital Signal Transmission Frequency:9600bit/s

Power Supply Cycle:400ms

Current: 2mA-500mA Optional

Signal Input Range: ≤ ± 10V

Continuous Working Time: ≤ 24hr

Power Consumption: <200W

Volume: 420*260*210mm

Weight:<7kg

Working Temperature Range:-1°C~+50°C

Working Power Supply: AC220V ± 10% 50Hz ± 5%

Logging Speed: 0~30m/min Adjustable(as per sampling interval)
