Openhole Wireline Logging Tester for Well Testing
1.Coal Field Digital Integrated Logging
2.Hydrological Engineering Digital Integrated Logging
3.Solid Metal Ore Digital Integrated Logging
4.Other Minerals Digital Integrated Logging
5.External Laptop (Desktop PC)
6.For upward logging, also for downward logging
7.Receive digital signal, analog signal
8.8 taps of power supply current, Optional
9.Automatic sampling as per depth interval, sampling interval arbitrarily
10.Indoor simulation logging, repeatability observation of instruments and probes
11.Membrane panel, attractive and durable.
Technical Specifications
1.12bit A/D Conversion, Program-Controlled Magnification K=0.5~128
2.Counting Channel: f≤500KHz
3.Digital Signal Transmission Frequency: 9600bit/s
4.Power Supply Cycle: 400ms
5.Current: 2mA~500 mA Optional
6.Signal Input Range: ≤±10V
7.Continuous Working Time: ≤24 hr
8.Power Consumption: <200W
9.Volume: 420×260×210mm
10.Weight: <7Kg
11.Working Temperature Range: -10°C~ +50°C
12.Working Power Supply: AC220V±10% 50Hz ±5%
13.Logging Speed: 0~30 m/min Adjustable (as per sampling interval).
