Heat Shrink Busbar Insulation Sleeve

Name: Heat Shrink Busbar Insulation Sleeve
Brand: zhizheng
SKU: 128890129
Availability: InStock

Negotiable MOQ: 500 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hubei, China

Brand Name:

zhizheng

Model Number:

MPG

Huangshi Zhizheng Rubber & Plastic New Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai ningbo other ports available

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name zhizheng

Model Number MPG

Type Insulation Sleeving

Material Other, crosslinked polyolefin

Application High Voltage

Rated Voltage 10kv

Tensile Strength 14Mpa

Specifications

10kv electrical insulation material
excellent fire resistan
good heat resistant
flexible,easy to use
high security

Detailed description of products:

High flame retardant: oxygen index greater than 30

Excellent heat resistance: long-term and stable operation under 105 centigrade degree

Low temperature resistance: not brittle crack under -55 centigrade degree

Good insulation: narrow the distance between interphase and to ground, meet the busbar's insulation requirment

Good flexibility: adapt to complex busbar shape and easy to install

Easy phase separation: have different colors

High security: prevent the short circuit caused by small animals and casualty accident caused by personal contact

Item	Test Methods	Required Index	Typical Test Data
Tensile Strength	ASTM D 638	above 12Mpa	15Mpa
Breakage Elongation Rate	ASTM D 638	above 350%	400%
Volume Resistivity	IEC 93	above 10¹⁴Ω.cm	2×10¹⁴Ω.cm
Water Absorption	ISO 62	below 0.5%	0.15%
Tensile Strength (After Heating Aging)	158 cetigrade degree aging 7 days	above 10Mpa	14Mpa
Breakage Elongation Rate (After Heating Aging)	158 cetigrade degree aging 7 days	above 300%	410%
Breakdown Strength	IEC 243	above 20kv/mm	23kv/mm
Voltage Resistant	----------------------	45kv no breakdown for 60 seconds	PASS
Partial Wall Rate	----------------------	below 30%	20%
Axial Direction Shrinkage	200 centigrade degree shrinking 3 minutes	-5~5%	-0.5%
