Cheap Price Rohs Autherized PE Heat Wrap Tube
cheap price Rohs autherized PE heat wrap tube
Specification
LRS1 series cheap price Rohs autherized PE heat wrap tube is widely used in electronic,electricity,military industry,ships building industry and so on, cheap price Rohs autherized PE heat wrap tube is mainly use to protect wire harness,labeling wire conductors,insulating protective of wire splices,electronic components,low voltage bus bard protective and pipes anti-corrosion etc.
Features
Shrink ratio:2:1
Consistent working temperature:-55~125centigrade
The lowest temperature performance:90centigrade
Flame resistant level:VW-1
No halogen
Passed EU RoHS ECO-protection instruction testing
Tensile strength 16MPA
Breakage elongation rate(%) 350%
Voltage resistant 20kv
Copper stability 158centigrade 7days no corrosion
Fire resistant vw-1
Our Services:
1.Payment Terms:T/T transfer, Paypal, Western Union.
2.Delivery time: 10 to 15 days upon quantity.
3. Samples could be offered free withn 1 to 5 meters, but the express charge is on the customer’s side.
4.Prompt reply and enthusiastic service.
Company Information:
We are manufactuer of heat shrink tubes for more than 15 years. Our products are widely exported to Asia, North America and Europe etc. We promise to supply you our products in great quality and competitive price.
FAQS:
Things needs to be confirmed before quotation:
1.What type of the heat shrink tube do you need?
1.) Single wall flame retardant heat shrink tube 2.)Adhesive lined double wall heat shrink tube 3.)1KV/11KV/36KV Busbar protection heat shrink tube 4.) Medium wall heat shrink tubes (You can visit our product catergories in our website on alibaba.)
2.What size (inner diameter of the tube)?
Look at the Specification chart.
3.What Color?
Color available: black,white,red,yellow,green,blue, more colors available upon request
| Specifications | before shrinkage(mm) inner diameter D | after shrinkage(mm) | package meter/roll | |
| inner diameter d | wall thickness t | |||
| Φ0.8 | 1.2±0.3 | 0.4±0.1 | 0.30±0.05 | 200 |
| Φ1.0 | 1.4±0.3 | 0.4±0.1 | 0.35±0.05 | 200 |
| Φ1.5 | 1.9±0.3 | 0.6±0.1 | 0.35±0.05 | 200 |
| Φ2.0 | 2.4±0.3 | 0.9±0.1 | 0.40±0.05 | 200 |
| Φ2.5 | 2.9±0.3 | 1.1±0.1 | 0.40±0.05 | 200 |
| Φ3.0 | 3.4±0.3 | 1.4±0.1 | 0.40±0.05 | 200 |
| Φ3.5 | 3.9±0.3 | 1.6±0.1 | 0.40±0.05 | 200 |
| Φ4.0 | 4.4±0.3 | 1.8±0.1 | 0.45±0.05 | 200 |
| Φ4.5 | 4.8±0.3 | 1.9±0.1 | 0.45±0.05 | 100 |
| Φ5.0 | 5.4±0.3 | 2.3±0.2 | 0.50±0.05 | 100 |
| Φ6.0 | 6.4±0.4 | 2.8±0.2 | 0.50±0.05 | 100 |
| Φ7.0 | 7.4±0.4 | 3.3±0.2 | 0.55±0.05 | 100 |
| Φ8.0 | 8.4±0.4 | 3.8±0.2 | 0.55±0.05 | 100 |
| Φ9.0 | 9.4±0.4 | 4.3±0.2 | 0.55±0.05 | 100 |
| Φ10 | 10.5±0.4 | 4.8±0.2 | 0.55±0.05 | 100 |
| Φ11 | 11.5±0.4 | 5.3±0.2 | 0.55±0.05 | 100 |
| Φ12 | 12.5±0.4 | 5.7±0.3 | 0.55±0.05 | 100 |
| Φ13 | 13.5±0.4 | 6.2±0.3 | 0.55±0.05 | 100 |
| Φ14 | 14.5±0.4 | 6.7±0.3 | 0.55±0.05 | 100 |
| Φ15 | 15.5±0.5 | 7.2±0.3 | 0.55±0.05 | 100 |
| Φ16 | 16.5±0.5 | 7.7±0.3 | 0.55±0.05 | 100 |
| Φ17 | 17.5±0.5 | 8.2±0.3 | 0.55±0.05 | 100 |
| Φ18 | 19.0±0.5 | 8.7±0.3 | 0.60±0.05 | 100 |
| Φ20 | 21.0±0.5 | 9.7±0.3 | 0.60±0.05 | 100 |
| Φ22 | 22.8±0.8 | 10.0±1.0 | 0.60±0.05 | 25 |
| Φ25 | 25.8±0.8 | 11.0±1.0 | 0.65±0.05 | 25 |
| Φ28 | 28.8±0.8 | 13.0±1.0 | 0.65±0.05 | 25 |
| Φ30 | 30.8±0.8 | 14.0±1.0 | 0.70±0.05 | 25 |
| Φ35 | 35.0±0.8 | 16.0±1.0 | 0.70±0.05 | 25 |
| Φ40 | 41.0±1.0 | 19.0±1.0 | 0.75±0.05 | 25 |
| Φ50 | 51.0±1.0 | 24.0±1.0 | 0.80±0.05 | 25 |
| Standard color: black, red, yellow, green, blue, white, transparent | ||||
