GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube

GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube thumbnail-1
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube thumbnail-2
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube thumbnail-3
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube thumbnail-4
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube thumbnail-5
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube thumbnail-6
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube photo-1
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube photo-2
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube photo-3
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube photo-4
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube photo-5
GOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube photo-6
US$ 0.018 - 0.05 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
Zhizhengtube
Model Number:
LRS1
Contact Supplier Request Quote Chat Now
Huangshi Zhizheng Rubber & Plastic New Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hubei, China
Brand Name Zhizhengtube
Model Number LRS1
Type Insulation Sleeving
Material PE
Application Low Voltage
Rated Voltage 20KV
Tensile Strength 400%

Good Quality Flexibility PE/EVA Heat Shrink Tube



Specification

LRS1 series Good Quality Flexibility PE/EVA Heat Shrink Tube  is widely used in electronic,electricity,military industry,ships building industry and so on,Good Quality Flexibility PE/EVA Heat Shrink Tube is mainly use to protect wire harness,labeling wire conductors,insulating protective of wire splices,electronic components,low voltage bus bard protective and pipes anti-corrosion etc.



Features

Shrink ratio:2:1

Consistent working temperature:-55~125centigrade

The lowest temperature performance:90centigrade

Flame resistant level:VW-1

No halogen

Passed EU RoHS ECO-protection instruction testing

Tensile strength 16MPA

Breakage elongation rate(%) 350%

Voltage resistant 20kv

Copper stability 158centigrade 7days no corrosion

Fire resistant vw-1



GOOD QUALITY Flexibility PE AND EVA Heat Shrink TubeGOOD QUALITY Flexibility PE AND EVA Heat Shrink TubeGOOD QUALITY Flexibility PE AND EVA Heat Shrink TubeGOOD QUALITY Flexibility PE AND EVA Heat Shrink Tube



Our Services:

1.Payment Terms:T/T transfer, Paypal, Western Union.

2.Delivery time: 10 to 15 days upon quantity.

3. Samples could be offered free withn 1 to 5 meters, but the express charge is on the customer’s side.

4.Prompt reply and enthusiastic service.





Company Information:

We are manufactuer of heat shrink tubes for more than 15 years. Our products are widely exported to Asia, North America and Europe etc. We promise to supply you our products in great quality and competitive price.







FAQS:

Things needs to be confirmed before quotation:

1.What type of the heat shrink tube do you need?

1.) Single wall flame retardant heat shrink tube  2.)Adhesive lined double wall heat shrink tube 3.)1KV/11KV/36KV Busbar protection heat shrink tube 4.) Medium wall heat shrink tubes (You can visit our product catergories in our website on alibaba.)

 2.What size (inner diameter of the tube)?

Look at the Specification chart.

3.What Color?

Color available: black,white,red,yellow,green,blue, more colors available upon request



Specifications before shrinkage(mm)
inner diameter   D		 after shrinkage(mm) package
meter/roll
inner diameter   d wall thickness   t
Φ0.8 1.2±0.3 0.4±0.1 0.30±0.05 200
Φ1.0 1.4±0.3 0.4±0.1 0.35±0.05 200
Φ1.5 1.9±0.3 0.6±0.1 0.35±0.05 200
Φ2.0 2.4±0.3 0.9±0.1 0.40±0.05 200
Φ2.5 2.9±0.3 1.1±0.1 0.40±0.05 200
Φ3.0 3.4±0.3 1.4±0.1 0.40±0.05 200
Φ3.5 3.9±0.3 1.6±0.1 0.40±0.05 200
Φ4.0 4.4±0.3 1.8±0.1 0.45±0.05 200
Φ4.5 4.8±0.3 1.9±0.1 0.45±0.05 100
Φ5.0 5.4±0.3 2.3±0.2 0.50±0.05 100
Φ6.0 6.4±0.4 2.8±0.2 0.50±0.05 100
Φ7.0 7.4±0.4 3.3±0.2 0.55±0.05 100
Φ8.0 8.4±0.4 3.8±0.2 0.55±0.05 100
Φ9.0 9.4±0.4 4.3±0.2 0.55±0.05 100
Φ10 10.5±0.4 4.8±0.2 0.55±0.05 100
Φ11 11.5±0.4 5.3±0.2 0.55±0.05 100
Φ12 12.5±0.4 5.7±0.3 0.55±0.05 100
Φ13 13.5±0.4 6.2±0.3 0.55±0.05 100
Φ14 14.5±0.4 6.7±0.3 0.55±0.05 100
Φ15 15.5±0.5 7.2±0.3 0.55±0.05 100
Φ16 16.5±0.5 7.7±0.3 0.55±0.05 100
Φ17 17.5±0.5 8.2±0.3 0.55±0.05 100
Φ18 19.0±0.5 8.7±0.3 0.60±0.05 100
Φ20 21.0±0.5 9.7±0.3 0.60±0.05 100
Φ22 22.8±0.8 10.0±1.0 0.60±0.05 25
Φ25 25.8±0.8 11.0±1.0 0.65±0.05 25
Φ28 28.8±0.8 13.0±1.0 0.65±0.05 25
Φ30 30.8±0.8 14.0±1.0 0.70±0.05 25
Φ35 35.0±0.8 16.0±1.0 0.70±0.05 25
Φ40 41.0±1.0 19.0±1.0 0.75±0.05 25
Φ50 51.0±1.0 24.0±1.0 0.80±0.05 25
Standard color: black, red, yellow, green, blue, white, transparent
