US$ 8,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Food, Apparel, Beverage, Chemical
Packaging Type:
Bottles, Cans, Film, Barrel, Bottles, Cans, Cartons
Contact Supplier Request Quote Chat Now
Qingdao Shunyi Plastech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Food, Apparel, Beverage, Chemical
Packaging Type Bottles, Cans, Film, Barrel, Bottles, Cans, Cartons
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 380V 50HZ
Power 24KW
Place of Origin Shandong, China
Brand Name Shunyi
Model Number ST6040A+BSE640A
Dimension(L*W*H) L6500mmxW3200mmxH2100
Weight 1000KG
Certification SGS
After-sales Service Provided Overseas third-party support available
Product Description

Wrapping Machine Type shrink machine &sealing machine for bottle

Suitable use scope:
This series of models using hot air circulation shrink, mainly shrink label for bottle-shaped bottle, jars, cups etc.
For food, beverages, pharmaceuticals, cosmetics, pesticides and other industries glass bottles, plastic bottles, cups and other containers, bottle r cup body heat shrikable sleeve label after label



Full-automatic Sleeve(without tray) Sealing and Shrink Wrapping Machine ST-6030AH+SM-6040M
Model
ST-6030AH
SM-6040M
Machine type L×W×H(mm)
1384×2716×1991
2800×900×1690
Tunnel dimension L×W×H(mm)
/
1800×600×400
Max. packing size L×W×H(mm)
400×300×300
1300×400×300
Sealing size length (mm)
700
/
Temperature(℃)
0-200
0-400
Work table height(mm)
850±50
850±50
Packing speed (pcs/min)
6-14
25-30
Machine weight (kg)
490
600
Power(kw)
1.5
24
Power
3PH380V50Hz
3PH380V50Hz
Air pressure(kg/cm²)
6-8
/
Application film
PE
PE

Technical Advantages:

1> Designed for packaging bottles with or without a tray, connectable to the production line , auto feeding film wrapping, sealing& cutting, shrinking and cooling. Different packaging modes
2> State-of-the-art technology and artwork adopted, machine's stability and reliability guaranteed.
3> OMRON PLC adopted to realize the integration of the machine, electricity and air
4> Imported advanced manufacturing technology adopted with unique appearance
5> Automatic combination packaging such as heap-tidying in 5 layers/4 layers/3 layers/2 layer or in multi-rows fulfilled without additional moulds.
6> Stable conveying and film feeding ensured via the adoption of the worm gear reducer, ensure
Special sealing blade to prevent film crack and sticking.
7> Optional auto feeding system according to the bottle shape
8> Color code locating system needed to seal color film
9> Precise location via the introduction of the imported photoelectric system
10> The conveying belt can be set on the left or right side according to the customer request
11> Double blowing motors adopted to dissipate the hot wind uniformly in the tunnel to achieve better effect after shrinking
12> Fed by poles chain which selects solid steel pole covered by imported silica gel, durable and bearable high tension after long time use
13> Transducer adopted to control the conveying speed; stepless speed changing.
14> Human-oriented designed control box easy to operate




Packaging & Shipping

Wrapping Machine Type shrink machine &sealing machine for bottle

Packaging Details: Packing by steel frame or wooden case suitable container sea transport;

Delivery Detail: Shipped in 15 days after payment
