Fiber Optic Gyro Inclinometer and Well Logging Equipment
1. Applications:
Adopting high precision fiber optic gyro as direction measurement sensor. Suitable used to measure inclination and direction
in the magneticmine area or inside iron casing.
2. Features:
1. All solid state structure, strong vibration control ability
2. Automatic search north
3. High accuracy measure, automatic store data
4. Probe suitable connect to integratd well logging system
5. System component
6. Main instrument, well logging probe, winch and cable
3. Technical Specifications:
1. Inclination Measuring Range 0 ~ 45°, Error ≤ 0.1°;
2. Azimuth Measuring Range 0~360°, Error ≤ 2 ° (1°≤Inclination≤45°);
3. Static Drift ≤ 4°, Non-Linearity of Drift ≤ 1°;
4. Measurement Mode: (frequency: 1 time/90 sec);
5. Gyro Service Life ≤ 3000 hours;
6. Probe Outline Dimension: φ38×2100mm;
7. Measured Well Depth ≤ 2000m;
8. Probe Pressure-Proof ≤ 200kg/cm2;
9. Instrument Working Power Supply: AC220V±10%, 50Hz ±5%;
10. Working Environment: Temperature: -10°~ 70°;Humidity: 90% (40°C)
11. Instrument Outline Dimension: 305×200×210mm;
12. Weight: 9 kg
Model |
40FW |
50F |
Measure Range |
Vertex angle;0°~50°Azimuth:0~360° |
Vertex angle;0°~50°Azimuth:0~360 |
Measurement Accuracy |
Vertex angle error:±0.2°Azimuth error: Vertex 1°~50°,< ±3° Direction drifting:<0.3°/h |
Vertex angle error:±0.2°Azimuth error: Vertex 1°~50°, < ±3° |
Measurement Depth |
1500m (Temperature<60°C) |
1500m (Temperature<60°C) |
Measurement Mode |
Point measurement |
Point measurement |
Probe Overall Dimension and Weight |
Φ40mm*1600mm/10kg |
Φ50mm*1680mm/9kg |
