FD18 1800kg Diesel Forklift

Henan Torin Industrial & Trading Co., Ltd.
FD18 1800kg Diesel Forklift thumbnail-1
FD18 1800kg Diesel Forklift photo-1
US$ 10,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Torin
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name Torin
Model Number FD18
Type Manual Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 1800kg
Max. Lifting Height 1955mm
Min. Lifting Height 105mm
Fork Length 920mm
Fork Width 35mm
Overall Dimensions 2250*1086*1955
Certification CE&ISO
After-sales Service Provided Overseas service center available

Specifications

1800kg diesel forklift
1.China Engine,controller
2.CE & ISO 9001 certificated
3.1 year or 1000 hours warranty

1800kg diesel forklift
1.China Engine

2.CE & ISO 9001 certificated
3.1 year  or 1000 hours‘ warranty





We supply varieties forklift truck such as 1-10 tons internal combustion counterbalance forklift truck, battery forklift truck,electric forklift truck, stone handling forklift trucks,also excavators,dump truck made in China.





FD series Forklift Features:



1.Good lighting:There are five transparent plastic covers on the top,so it has good lighting effect and waterproof function



2.Wide visual field :Widen msat design, open visual field , increase the work efficiency and safety operarion



3.Beautiful display meter :LCD display meter,feedback the working condition in time,integrated electric system,testing and maintenance easily



4.Spacious space :Operating space increase by 10 percent ,make the driver's operating more comfortable.



5.Excellent effect of distribute heat :Air vent on the back of the forklift increase by 10 percent, which is benefit water tank to istribute heat











Technical Specification



  Parameter NameUnitFD15FD18
SpecialityPower model DieselDiesel
Rated capacitykg15001800
Load centermm500500
Lifting heightmm30003000
Free lifting heightmm115115
Size of forks (L*W*H)mm920*100*35920*100*40
Mast tilt angle(Front/Back).6/126/12
Minimum turning radiusmm20602060
Minimum right-angle stacking aisle widthmm36803680
Minimum right-angle aisle widthmm18651865
Minimum ground clearancemm105105
Overhead guard heightmm20402040
Front overhangmm400400
performanceMax driving speed (Full load)km/h14.514.5
Max lifting speed (Full load/Without load)km/h460/500460/510
Max tractive force (Full load)KN1616
Max grade ability%2020
SizeOverall length( No forks)mm22502250
Overall widthmm10861086
Max fork lifting height(With load backrest)mm38603860
Mast heightmm19551955
ChassisTyre               Front wheelmm6.50-10-10PR6.50-10-10PR
Tyre               Back wheelmm5.00-8-10PR5.00-8-10PR
Axle basemm14001400
Wheel span(Front/Back)mm890/920890/920
Dead weight(No load)kg26802890
drive Battery               Voltage/CapacityV/Ah12/9012/90
EngineModel XINGCHANG485BPGXINGCHANG485BPG
Rated powerkw/r.p.m30/260030/2600
Rated torqueNm/r.p.m131/1800131/1800
Cylinders diameter *Strokemm0.985*100
Number of cylinders 4.04.0
displacementL2.272.27
Fuel tank capacityL4545
Transmission Gear position Front/Back 2/2 Manual shift         1/1 Power shfit
Working pressureMpa14.5





 FD18 1800kg diesel forkliftFD18 1800kg diesel forklift
