Help CenterGeoelectric Induced Polarization Instrument For Water Detection
Related Products
-
Geological Resistivity Survey Instrument For Deep Ground Water DetectionUS$ 1 - 24,500MOQ: 1 Set -
2016 New!!! Geophysical Equipment For Sale, Geophysical Equipment PriceNegotiableMOQ: 1 Set
-
VES Geophysical Instrument, Vertical Electrical Sounding Instrument for Ground Water Exploration and Hydrologic ExplorationNegotiableMOQ: 1 Set
-
Geophysical Resistivity For Groundwater Detector and Underground Water FinderNegotiableMOQ: 1 Set
-
Underground Water Detector DDC-8 Ground Water DetectorUS$ 1 - 2MOQ: 1 Set
Underground Water Finder DZD-6A 500m Underground Water Finder
Payment & Shipping Terms |
Supply Capacity |
||
Payment term : |
T/T or L/C |
Production capacity : |
500pcs/month |
MOQ: |
1 pc |
Packing : |
Wooden case |
Price |
negotiable |
Delivery way |
By Air |
Means of transport : |
FOB , CIF , CFR |
Delivery time : |
10 days |
Place of Origin |
Chongqing, China (Mainland) |
Brand Name |
Gold |
Model Number |
Underground Water Locator Resistivity Meter and IP Meter
|
usage |
Underground Water Locator Resistivity Meter and IP Meter |
Geoelectric Machine For Ground Water Detection Geo Electric
Geophysical Instrument Manufacturers For Underground Structure
Main Applications
1 By utilizing relevant parameters of apparent resistivity and induced polarization method, the instrument is widely used in many aspects including metal and non-metal mineral resources exploration, energy exploration, city geophysical exploration, railway and bridge engineering exploration, etc.
2 Search for groundwater, solve the human and animal drinking water issue as well as industrial and agricultural water issue. Determine the hidden safety risk location in reservoir dam foundation and flood-control dyke, find faultage zone and collapse column, landslides, coal mining goaf, search for geothermal and other hydrological, engineering geological exploration.
3 Accessories made by our factory with 60-channel or 120-channel multiplex electrode switch, also can be used for multi-electrode resistivity survey system.
Receiving Part
1 Measuring Voltage Range: -6000mV~+6000mV
2 Measuring Voltage Resolution: 0.01 mV
3 Measuring Voltage Accuracy: (at Vp>10mV)±5%, ±1 digit; (at Vp<10mV)±1%, ±1 digit
4 Measured Apparent Polarizability Accuracy: ±1%, ±1 digit
5 Measuring Current Range: 0~5000 mA
6 Measuring Current Resolution: 0.01 mA
7 Measuring Current Accuracy: (at Ip>10mA)±5%, ±1 digit; (at Ip<10mA)±1%, ± digit
8 Input Impedance: ≥50MΩ
9 Interference Suppression on 50Hz Power Frequency: Better than 80dB
Transmitter Part
1 Maximum Transmitting Power: 4500 W
2 Maximum Power Supply Voltage 900V
3 Maximum Power Supply Current: 5A
4 Instrument has over-voltage and over-current protection devices
5 Power Pulse Width: 1-60 seconds, Duty Cycle 1:1
