China supply Geophysics Research Equipment for ground water locator
Main Applications about ground water locator:
By utilizing relevant parameters of apparent resistivity and induced polarization method, the instrument is widely used in many aspects including metal and non-metal mineral resources
exploration, energy exploration, city geophysical exploration, railway and bridge engineering exploration, etc.
Search for groundwater, solve the human and animal drinking water issue as well as industrial and agricultural water issue. Determine the hidden safety risk location in reservoir dam foundation and flood-control dyke, find faultage zone and collapse column, landslides, coal mining goaf,
search for geothermal and other hydrological, engineering geological exploration.
Accessories made by our factory with 60-channel or 120-channel multiplex electrode switch, also can be used for multi-electrode
resistivity survey system.
Main features about ground water locator:
1,Small-sized, Light in weight: The instrument integrates receiver and transmitter
together in the same cabinet, which can be used for measurement via apparent
resistivity method and induced polarization method.
2,Various Measurement Parameters: Instrument can be applied in direct measurement and
indication of primary potential Vp, spontaneous potential Vsp,power supply current I,
apparent resistivity Ro, apparent polarizability Ms, half-decay time Th,degree of
decay D,integrated IP parameters Zp, and degree of deviation R.
Technical specifications about ground water locator:
Receiving Part
Measuring Voltage Range: -6000mV~+6000mV
Measuring Voltage Resolution: 0.01 mV
Measuring Voltage Accuracy: (at Vp>10mV)±5%, ±1 digit; (at Vp<10mV)±1%, ±1 digit
Measured Apparent Polarizability Accuracy: ±1%, ±1 digit
Measuring Current Range: 0~5000 mA
Measuring Current Resolution: 0.01 mA
Measuring Current Accuracy: (at Ip>10mA)±5%, ±1 digit; (at Ip<10mA)±1%, ± digit
Input Impedance: ≥50MΩ
Interference Suppression on 50Hz Power Frequency: Better than 80dB
Transmitter Part
Maximum Transmitting Power: 4500 W
Maximum Power Supply Voltage 900V
Maximum Power Supply Current: 5A
Instrument has over-voltage and over-current protection devices
Power Pulse Width: 1-60 seconds, Duty Cycle 1:1
Others Parameter
Working Temperature: -10°Cto +50°C, 95%Rh
Storage Temperature: 20°C to +60°C
Power Supply: 1# Dry Cell (or rechargeable battery with the same specification) 8 pcs
Machine Current: < 55 mA
Weight: 8 kg
Volume: 305×200×202 mm
More photos about ground water locator:
Full appearance:
Suitcase(easy to carry)
Wooden box packing(Export standard,and lower the damage in the transportation)
While test:
Test Data photograph:
Any questions about ground water locator,please contact Elsa:
Phone/whatsapp/wechat:0086-15922980256
Skype:goldinstrument
